(888) 312-8812 Login SignupGATES TR24308 Green Stripe Truck & Bus Series V-Belt
Tap to view 1 more
$2299
Limited availability at this price!
In Stock
Get it by Tuesday, Jan 13
GATES TR24308 Part Description
Manufacturer
Product Description
Green Stripe Truck & Bus Series V-Belt
Application Summary
John Deere, 12A, John Deere LUC, Fan
Features & Benefits
- Molded notches reduce bending stress, especially on small diameter pulleys, while dissipating heat
- High modulus, high strength tensile cord
- Oil and heat-resistant construction throughout
- Meets SAE J636b and SAE J637 specifications
- Meets RMA oil and heat resistant standards and static conductivity requirements
- NOTE: Some sizes available as Gates PowerBand joined V-belts
GATES TR24308 Specifications
Product Attributes
| Type | Truck & Bus V-Belt |
| Cross Section Designation | TA |
| Angle | 36 |
| Strand Quantity | 1 |
| Top Width | .656 in |
| Outside Circumference | 31.45 in |
| Effective Length | 30.87 in |
| Construction | Notched |
| Notched | Yes |
| Belt Material | EPDM |
| Cord Material | Polyester |
| Top Width | 17 mm |
| Outside Circumference | 799 mm |
| Effective Length | 784 mm |
Additional Information
| Country of Origin (Primary) | US |
| Harmonized Tariff Code (Schedule B) | 4010323000 |
| UPC | 00072053277906 |
| VMRS Code | 065005003 |
| UNSPSC | 26111801 |
GATES TR24308 Part Interchanges
| Brand | Part Number |
|---|---|
| Mopar | B-24307-A, BH-16 |
| White | 201A7, 3110K116, 660073, 660074, 700232, 7A6834 |
| ACDelco | T24308 |
| Dayco | 24308, 396M, 430302, 51361, 53664, 54326, 56241, 56279, 57443, 57573 |
| Carquest | TR24308 |
| Bando | 9305, 9300 |
| Cummins | 122867, 147099, 151138, 178522, 178664, 178667, S3120 |
| Diamond Reo | 3859B1310 |
| General Motors | 5117638, 5160523 |
| International Harvester (IHC) | 251428R1 |
| John Deere | L4264T |
| Mitsuboshi | RECMF3310 |
| Goodyear | 24307, 24313 |
| NAPA Belts/Hose | 25-24308 |
| MBL Three Stars | 24310 |
| NAPA | 25-07800 |
| <Unknown> | 24314, 4004680, 5113678, 700232A7 |
| Metric | 17A0780 |
GATES TR24308 Cross References
We have 1 alternatives for the TR24308 by GATES:
