(888) 312-8812 Login SignupGATES G20300-2016 Code 61 O-Ring Flange (GlobalSpiral)
Tap to view 3 more
$6899
Limited availability at this price!
In Stock
Get it by Monday, Jul 27
GATES G20300-2016 Part Description
Manufacturer
Product Description
Code 61 O-Ring Flange (GlobalSpiral)
Features & Benefits
- "Bite-the-wire" crimp for improved coupling retention
- “Bite-the-wire” crimp for improved coupling retention
- Tested to an industry-leading 1,000,000 impulse cycles
- +250degF temperature capability for longer assembly life
- +250°F temperature capability for longer assembly life
- +250?F temperature capability for longer assembly life
- +250˚F temperature capability for longer assembly life
- Environmentally-friendly TuffCoat plating for 347 percent better corrosion resistance than the SAE Standard
GATES G20300-2016 Specifications
Product Attributes
| Coupling Description | GlobalSpiral Code 61 O-Ring Flange |
| Industrial Description | 20GS-16FL |
| Inside Diameter | 1.25 IN |
| Hydraulic Hose Recommendation | All Gates MegaSys Four and Six-Spiral Wire Hydraulic Hose Up to 8,000 psi |
| Maximum Working Pressure | 5000 PS |
| Flange Thickness | .32 in |
| Flange Diameter | 1.75 IN |
| Cut-Off Length | 2.56 IN |
| Length | 5.35 IN |
| Inside Diameter | 31.8 MM |
| Flange Thickness | 8.1 MM |
| Flange Diameter | 44.5 MM |
| Cut-Off Length | 64.9 MM |
| Length | 135.9 MM |
Additional Information
| Harmonized Tariff Code (Schedule B) | 8412909015 |
| Country of Origin (Primary) | US |
| Stock Status | N |
| UPC | 00072053454727 |
| VMRS Code | 059032012 |
| UNSPSC | 31163000 |
GATES G20300-2016 Cross References
| Brand | Part Number |
|---|---|
| Aeroquip | 1B16FL20, 4S16FL20 |
| Dayco | 102085, 1B16FK20 |
| N/A | 04030918, M23311-20-16 |
| NAPA | G20300-2016 |
| Parker | 11571-16-20 |
