GATES 85479 Part Description
Manufacturer
Product Description
EFG4K Spiral Wire Hose - SAE 100R12
Features & Benefits
- For use with GlobalSpiral Couplings [G20 Series], GlobalSpiral One-Piece Couplings [G21 Series, -20 Only] and Stainless Steel Spiral Couplings [G18 Series]
- Tested to industry-leading 1,000,000 impulse cycles
- XtraTuff hose lasts up to 25 times longer than standard hose
- MegaTuff hose lasts up to 300 times longer than standard hose during hose-to-hose and hose-to-metal abrasion tests per ISO 6945 and offers superior ozone and weathering resistance
- Meets Flame Resistance Acceptance Designation MSHA 2G
- Temperature Range: -40 Deg. F to +250 Deg. F (-40 Deg. C to +121 Deg. C)
GATES 85479 Specifications
Product Attributes
| Type | Hydraulic Hose |
| Hose Pressure Description | Very High Pressure |
| Maximum Working Pressure | 4000 PS |
| Burst Pressure | 16000 PS |
| Temperature Rating | -40 Deg. F to +250 Deg. F (-40 Deg. C to +121 Deg. C) |
| Length | 25 FT |
| Dash Size | 10 |
| Inside Diameter | .625 IN |
| Outside Diameter | 1.09 IN |
| Bend Radius | 4 IN |
| Tube Description | Black, Oil-Resistant, Synthetic Rubber |
| Hose Material | Nitrile - Type C |
| Reinforcement Material | Four Alternating Layers of Spiraled, High-Tensile Steel Wire |
| Cover Material | Synthetic Rubber - Polychloroprene - Type A - Color Coded Layline |
| Cover Type | Type A - Flame & Oil Resistant |
| Cover Color | Black |
| Coupling Recommendation | GlobalSpiral, Stainless Steel S |
| SAE Standard | 100R12 |
| EN Standard | 856 R12 |
| ISO Standard | 18752 Grade D, 3862 Type R12 |
| Product Type | EFG4K Spiral Wire Hose - SAE 100R12 |
| Industrial Description | 10EFG4KX25FT |
Additional Information
| Harmonized Tariff Code (Schedule B) | 4009410000 |
| Country of Origin (Primary) | US |
| Stock Status | S |
| UPC | 00072053505849 |
| VMRS Code | 059032029 |
| UNSPSC | 40142020 |
GATES 85479 Cross References
| Brand | Part Number |
|---|---|
| Dayco | 010410, 010410X, M710 |
| N/A | EQ25 10-77, 04029741, EQ28 10-77 |
| NAPA | 85479 |
| Parker | 772TC-10-BX |
| Weatherhead | H35010, H43010-30 |
