(888) 312-8812 Login SignupGATES 6870 PoweRated FHP Medium Horse-Power V-Belt
Tap to view 2 more
$2899
Limited availability at this price!
In Stock
Get it by Thursday, Jul 23
GATES 6870 Part Description
Manufacturer
Product Description
PoweRated FHP Medium Horse-Power V-Belt
Application Summary
Allis-Chalmers, 410, , Belt
Features & Benefits
- Designed with distinct green color bareback construction for smooth clutching on shock loaded, backside idler-driven equipment to ensure high crack resistance
- Low, aramid tensile cord positioned in a thin profile gives extreme flexibility and limited stretch with extraordinary strength and durability
- Meets RMA oil and heat-resistant standards, but not for static conductivity
- Temperature Range: -22 Deg. F to +140 Deg. F (-30 Deg. C to +60 Deg. C)
- Note: Gates PoweRated V-belts can be substituted for equivalent sizes of FHP low horsepower Gates Truflex V-belts
GATES 6870 Specifications
Product Attributes
| Type | FHP Medium Horse-Power V-Belt |
| Cross Section Designation | 4L |
| Angle | 38 |
| Strand Quantity | 1 |
| Top Width | .5 in |
| Outside Circumference | 70 in |
| Effective Length | 70.18 in |
| Construction | Wrapped |
| Notched | No |
| Belt Material | EPDM |
| Cord Material | Aramid |
| Top Width | 13 mm |
| Outside Circumference | 1778 mm |
| Effective Length | 1783 mm |
Additional Information
| Country of Origin (Primary) | MX |
| Harmonized Tariff Code (Schedule B) | 4010323000 |
| Stock Status | S |
| UPC | 00072053004755 |
| VMRS Code | 065005003 |
| UNSPSC | 26111801 |
GATES 6870 Cross References
| Brand | Part Number |
|---|---|
| <Unknown> | 170, 17478, 20116P12C, 286129, 3516053, 5600056, 57935, 5H57964A700, 7AC30209, 90300006, 90733, 90748, A305, AC11330, C4A157, C4A89, J27B44, K810236336, K810236337, P3670, PA584, S863526, B114, E533936 |
| ACDelco | 4L700, 4L700P |
| Allis Chalmers | 108505, 1657589, 2027134 |
| American Floor Surface Machine | 2001161 |
| American Lincoln | 20003201 |
| Ariens | 072110 |
| BF Goodrich | 1700 |
| Bolens | 1716307 |
| Browning Manufacturing | 1680 |
| Bryant Mfg | 94036 |
| CARQUEST | 2700, 6870 |
| CONTINENTAL AG | 84700 |
| Campbell Hausfeld | BT99 |
| Case Tractor | C15943, C23806, C23809, H86039 |
| Dayco | 1M070, 4L700, 45762, 48X700, L470 |
| Demco | 6L172 |
| Deutz-allis | 72027134 |
| Dexter Co | C41 |
| Dresser | AC12101 |
| Durkee-Atwood | 48-700, XDV48-700 |
| Food Machine | 1706799, 1716307 |
| Ford | GB210752 |
| Frigidaire | EA134373, EA72063 |
| General Electric | K5705475AG41, K5705475AN51 |
| General Leisure | 530050022, 530050023 |
| Gilmer | 3700 |
| Gilson | 210752 |
| Goodyear | 74700, FA70, 48700, 84700, 4LK700 |
| Gould | 80703700 |
| Grainger | 4L700 |
| Gravely | 26132, 26143 |
| Hahn | 308476, 308505 |
| John Deere | LG48700, TY4418, H86039, M55258 |
| L Series | 4L700 |
| Lawn Boy | 608475 |
| MBL Three Stars | 4LK700 |
| Metric | 13R1780, 13RL1780 |
| Mono | 368333 |
| Mopar | B4L-700 |
| Myers | 5908A5 |
| NAPA Belts/Hose | 4L700, 4L700W, 2700 |
| Oregon | 75-770, 75-470 |
| PIX | A-4L700 |
| Penneys | 6142B |
| Power Lawnmower Part | 109-130 |
| Prime-Line | 7-4H700 |
| Reliance Electric | 108054 |
| Roper | 57955, 62828 |
| Rotary Lifts | 12-5103, 123453, 12-7513, 123785 |
| Rugg | 20843X |
| Sears | STD304700 |
| Sensation | 153802 |
| Shaw | S3553 |
| Silver Streak | 75-770, DB4L700, 75-470 |
| Simplicity | 1601520, 1605120, 1607051, 2029622 |
| Stens | 248-070 |
| Thermoid | 4H700 |
| Toro | 27169 |
| Troy | 30334 |
| U.S. Government | 3030005283828, MS392424L700 |
| Western International | 47390A |
| Wheel Horse | 107647, 108505, 1576, 8231, 9691 |
