(888) 312-8812 Login SignupGATES 360530 Power Steering Pressure Line Hose Assembly
No Stock Available
We cannot fulfill orders for this part at this time. Please check back later or request a stock notification to receive an email.
We may have similar parts for sale. Search Alternatives >
GATES 360530 Part Description
Manufacturer
Product Description
Power Steering Pressure Line Hose Assembly
Application Summary
1997-1992 Ford, Ranger, 4-Cyl. 2.3 L, Pressure
Features & Benefits
- Extensive field examination and testing assure proper fit
- For passenger cars and light trucks
- General instructions are packed with every assembly
- Hoses and fittings are also available for tailor-made medium and heavy-duty truck applications
- Comes complete with factory-installed, pre-bent zinc-dichromate plated end fittings, bracketry, sensor ports, sheathing, bushings and grommets
- Exceeds SAE J2050 performance requirements. (Product Type 7741)
GATES 360530 Specifications
Product Attributes
| Grade Type | OE Performance |
| Length | 28.75 IN |
| End Diameter | .3125 IN |
| End 1 Type | Male Inverted Flare |
| End 2 Type | Swivel O-Ring |
| Fully Assembled Pressure & Return Set | N/A |
| Switch Port Included | Yes |
| SAE Standard | Exceeds SAE J188 specifications |
| Tube Material | Zinc Single Wall Steel |
| Sleeve Material | Anti Corrosion Steel |
| Mounting Brackets Included | No |
| Sleeve Included | No |
| Washer(s) Included | No |
| Bushing Included | No |
| Mounts Included | No |
| Retainer Clips Included | N/A |
| Mounting Position | Pump to Rack/Gear Box |
Additional Information
| Country of Origin (Primary) | MX |
| Harmonized Tariff Code (Schedule B) | 4009320050 |
| UPC | 00072053425475 |
| VMRS Code | 065007006 |
| UNSPSC | 40141764 |
GATES 360530 Part Interchanges
| Brand | Part Number |
|---|---|
| Autoline | 5-4202 |
| Beck/Arnley | 109-2106 |
| Four Seasons | 120172 |
| Moog | M-4208 |
| MOOG Chassis Products | M-789 |
| ACDelco | 36-360530 |
| Everco | 67126, 67350, 67647, 67982 |
| Carquest | 36053 |
| Continental Belt | 14562, 14574, 14590 |
| GSL | 2-9767 |
| Ford | F07A 3A719 DA, F27A 3A719 HB, F2TZ 3A719 A, F37A 3A719 ABA, F37Z 3A719 A, F47A 3A719 RB, F47A 3A719 YA, F47Z 3A719 B |
| Mazda | ZZM032490, ZZM032490A |
| Omega | 4202, 4263, 4208, 789 |
| Edelmann | 71423, 71878 |
| NAPA | 36053, 7-2350, 7-2351 |
| SunSong | 3401104 |
GATES 360530 Fits Vehicles
- Ford F-100 Ranger (1996-1997)
- Mazda B4000 (1994-1997)
- Mazda B3000 (1994-1997)
- Mazda B2300 (1994-1997)
- Mazda Navajo (1991-1994)
- Ford Ranger (1990-1997)
- Ford Explorer (1991-1994)
- Ford Bronco II (1990)
GATES 360530 Cross References
We have 1 alternatives for the 360530 by GATES:
