(888) 312-8812 Login SignupGATES 3230 Truflex FHP Low Horse-Power V-Belt
Tap to view 2 more
$1299
Limited availability at this price!
5 Day Lead Time
Get it by Monday, Jul 27
GATES 3230 Part Description
Manufacturer
Product Description
Truflex FHP Low Horse-Power V-Belt
Application Summary
Brennan, E4, Diesel, Gen.
Features & Benefits
- Flex-bonded cords are strongly forged to the belt body, resulting in equal load distribution, resistance to fatigue and shock loads and the absorption of bending stress without cord deterioration
- Proprietary Flex-Weave cover is a patented fabric construction, providing extended protection to the belt core from oil, contaminants and heat for longer belt life
- Runs with smooth, quiet operation
- Meets RMA oil and heat-resistant standards and static conductivity requirements
- Available in 2L (0), 3L (1), 4L (2) and 5L (3) cross-sections
- Do not use on applications where FHP medium horsepower V-belts are recommended
GATES 3230 Specifications
Product Attributes
| Type | FHP Low Horse-Power V-Belt |
| Cross Section Designation | 5L |
| Angle | 34 |
| Strand Quantity | 1 |
| Top Width | .66 in |
| Outside Circumference | 23 in |
| Effective Length | 22.96 in |
| Construction | Wrapped |
| Notched | No |
| Belt Material | EPDM |
| Cord Material | Polyester |
| Top Width | 17 mm |
| Outside Circumference | 584 mm |
| Effective Length | 583 mm |
Additional Information
| Harmonized Tariff Code (Schedule B) | 4010391000 |
| Country of Origin (Primary) | MX |
| Stock Status | S |
| UPC | 00072053007015 |
| VMRS Code | 065005003 |
| UNSPSC | 26111801 |
GATES 3230 Cross References
| Brand | Part Number |
|---|---|
| <Unknown> | 15054, 356294 |
| ACDelco | 5L230 |
| CARQUEST | 3230 |
| CONTINENTAL AG | 5L230 |
| Dayco | 5L230 |
| Dille & Mcguire | WM382 |
| Goodyear | 5L230, 75230 |
| Grainger | 5L230 |
| L Series | 5L230 |
| Metric | 16R585 |
| Mopar | B5L-230 |
| NAPA Belts/Hose | 5L230, 3230 |
| PIX | A-5L230 |
| Power Lawnmower Part | 109-161 |
| Reliance Electric | 108625 |
| Roper | 529H |
| Rotary Lifts | 12-5150 |
| Silver Streak | DB5L230 |
