(888) 312-8812 Login SignupGATES 32056 Stainless Steel Hose Clamp
Tap to view 1 more
$3180
Package Price for 10 Units
@ $3.18 per unit
Limited availability at this price!
In Stock
Get it by Tuesday, Dec 30
GATES 32056 Part Description
Manufacturer
Product Description
Stainless Steel Hose Clamp
Features & Benefits
- Durable 200 series stainless steel band and screw housing
- One-piece screw housing is interlocked onto band for extra strength
- Cadmium-plated solid head forged from one piece of steel
- Hex-shaped screw has a deep slot that tightens with a screwdriver, nut driver or socket wrench
- NOTE: Tighten Minex clamps to minimum 14-16 in. lb. (maximum of 20 in. lb.)
- NOTE: Super Hex clamps to minimum 25-35 in. lb. (maximum of 50 in. lb.)
GATES 32056 Specifications
Product Attributes
| Adjustment Type | Stainless Steel (Standard) |
| Hose Clamp Size | 56 |
| Hose Minimum Inside Diameter | 2 IN |
| Hose Maximum Inside Diameter | 3.5 IN |
| Minimum Clamping Length | 2.125 IN |
| Maximum Clamping Length | 4 IN |
| Band Width | .5 IN |
| Screw Type | Deep Slot Hex-Head |
| Recommended Torque | 25-35 PPI |
| Maximum Torque | 50 IA |
| Material | Stainless Steel |
| Housing Material | Stainless Steel |
| Band Width | 13 MM |
Additional Information
| Country of Origin (Primary) | US |
| Harmonized Tariff Code (Schedule B) | 7326908688 |
| UPC | 00072053021745 |
| VMRS Code | 053008020 |
| UNSPSC | 31162900 |
GATES 32056 Part Interchanges
| Brand | Part Number |
|---|---|
| Interstate | 2056 |
| Norton | 013-56 |
| Velvac | 022356 |
| ACDelco | 32056C |
| Dayco | KH56, 91056 |
| Robertshaw | 2056 |
| Aero-Seal | M56S |
| Goodyear | 51056 |
| Ideal Tridon | 5756190, 670040056, 670040056051 |
| Ideal Hy-Gear | 5056, 5256, 5456, 6456 |
| Murray Gold Seal | GS 55 |
| NAPA | 705-1026, 705-1085, 705-1144 |
| Sure-Tite | C56P |
GATES 32056 Cross References
