GATES part description

Product Description

Green Stripe Heavy-Duty Vulco-Flex Coolant Hose

Application Summary

2003-1999 Kenworth, T2000, Cummins ISX Diesel, Upper - Pipe To Rad.

Features & Benefits

  • Engineered to resist electrochemical degradation, the leading cause of hose failure
  • Built-in steel spiral wire allows for medium sized curves without kinking or collapsing
  • EPDM tube and Neoprene cover for extended service life
  • Polyester fabric-ply reinforcement vulcanizes into shape without unnecessary strain on connections
  • Resistant to heat, oil and ozone
  • Performs to SAE 20R5 Type EC Class D-2 specifications
  • Temperature Range: -40 Deg. F to +257 Deg. F (-40 Deg. C to +125 Deg. C)
  • Caution: Do not use for fuel or oil transfer applications

Product Attributes

Centerline Length 24 IN
End 1 Inside Diameter 2.5 in
End 2 Inside Diameter 2.5 in
Material EPDM, Steel
9839 No

Additional Information

Country of Origin (Primary) MX
Harmonized Tariff Code (Schedule B) 4009410000
UPC 00072053065022
VMRS Code 042004061
UNSPSC 40142000

Part Interchanges

GATES 26532 Cross Reference

We have 1 alternatives for the 26532 by GATES:

Fits Vehicles

  • Kenworth K300 (1995)
  • Mack RW (1985)
  • Peterbilt 348 (1981-1984)
  • Peterbilt 353 (1982, 1984-1985)
  • Kenworth T2000 (1999-2000, 2002-2003)
