(888) 312-8812 Login SignupGATES 26507 Green Stripe Heavy-Duty Vulco-Flex Coolant Hose
$4049
Limited availability at this price!
In Stock
Get it by Tuesday, Dec 16
GATES 26507 Part Description
Manufacturer
Product Description
Green Stripe Heavy-Duty Vulco-Flex Coolant Hose
Application Summary
Austin-Western, 714, Detroit Diesel 4-53 Diesel, Lower
Features & Benefits
- Engineered to resist electrochemical degradation, the leading cause of hose failure
- Built-in steel spiral wire allows for medium sized curves without kinking or collapsing
- EPDM tube and Neoprene cover for extended service life
- Polyester fabric-ply reinforcement vulcanizes into shape without unnecessary strain on connections
- Resistant to heat, oil and ozone
- Performs to SAE 20R5 Type EC Class D-2 specifications
- Temperature Range: -40 Deg. F to +257 Deg. F (-40 Deg. C to +125 Deg. C)
- Caution: Do not use for fuel or oil transfer applications
GATES 26507 Specifications
Product Attributes
| Centerline Length | 9.5 IN |
| End 1 Inside Diameter | 2 in |
| End 2 Inside Diameter | 2 in |
| Material | EPDM, Steel |
| Molded | No |
| Centerline Length | 241 MM |
| End 1 Inside Diameter | 51 MM |
| End 2 Inside Diameter | 51 MM |
Additional Information
| Country of Origin (Primary) | MX |
| Harmonized Tariff Code (Schedule B) | 4009410000 |
| UPC | 00072053064773 |
| VMRS Code | 042004061 |
| UNSPSC | 40142000 |
GATES 26507 Part Interchanges
| Brand | Part Number |
|---|---|
| Mopar | BH-632 |
| Motorcraft | KD-094 |
| White | 1701366, 1732989, 654386 |
| ACDelco | 31706 |
| Dayco | 2009, 2009HD, 81401, 82061, 82061GL, M17, M69 |
| BF Goodrich | 809, 2007, 2009 |
| CARQUEST | 26507 |
| Allis Chalmers | 8064 |
| Atlas (Canada) | FH4 |
| Caterpillar | A628391C1 |
| Clark Equipment | 1307489, 1927304, 531170, 786626, 941440, PGF13678A |
| Diamond Reo | N91204B |
| Epton | 809, 2007, 2009 |
| Food Machine | 1407227, 1409863 |
| General Motors | 1436216 |
| Ford | C1TT 8286 S, C9PZ 8260 AC |
| International Harvester (IHC) | 150722, 151756, 253840C12, 273865C11, 284580C1, 284580C11, 304597R1, 306918R1, 371307R1, 412997C1, 622464C1, 987457R1 |
| John Deere | T61478 |
| Hyster | 145367, 149073, 152937, 178818 |
| Reo Trucks | 972F243, 972F270, 972F283, N9203K |
| Studebaker | 503P593 |
| Mobil | 8M7, 8M9 |
| Goodyear | 53209 |
| Volvo GM Heavy Truck | V1092190 |
| NAPA Belts/Hose | FM66 |
| Autopar | RH93 |
| Durkee-Atwood | 809, 807 |
| Eaton, Yale & Towne | 500006902 |
| Globe Lifeline | 2007, 2009 |
| Westinghouse | WA7819M17 |
| <Unknown> | 1219179, 1244154, 169436, 544016, 666446, H62170, PGE13678A, RD55414, Y682924 |
| Continental Belt | 53209 |
GATES 26507 Fits Vehicles
- International Scout (1961-1970)
GATES 26507 Cross References
We have 1 alternatives for the 26507 by GATES:
