Gates 20774 - Premium Molded Coolant Hose
$1899
In stock
limited availability at this price!
Pay over 3-12 months with
. Learn more
. Learn more
GATES part description
Product Description
Premium Molded Coolant Hose
Application Summary
1991-1990 International/Navistar, 4900, International/Navistar DT466 Diesel, By Pass
Features & Benefits
- Specifically-engineered materials resist collapse under vacuum
- Specifically-engineered materials resist collapse under vacuum
- Engineered to resist electrochemical degradation, the leading cause of hose failure
- Pre-shaped to fit and to ensure perfectly sealed conditions
- EPDM tube; synthetic fiber knit reinforcement; heat-, ozone- and chemical coolant-resistant EPDM cover
- Meets requirements of SAE 20R4, class D2 and DIN 73411, class A (except for tolerances)
- Temperature Range: -40 Deg. F to +257 Deg. F (-40 Deg. C to +125 Deg. C)
- Note: Gates recommends replacing hose clamps each time a new coolant hose is installed
- Caution: Do not use for fuel or oil transfer applications
Product Attributes
| Centerline Length | 11.3 IN |
| Modular | No |
| Branch Quantity | 0 |
| Quick Connect Fitting Quantity | 0 |
| End 1 Inside Diameter | 1.25 in |
| End 2 Inside Diameter | 1.25 in |
| Contains Spring | No |
| Material | EPDM |
| Molded | Yes |
| Centerline Length | 287 MM |
| End 1 Inside Diameter | 32 MM |
| End 2 Inside Diameter | 32 MM |
Additional Information
| Country of Origin (Primary) | US |
| Harmonized Tariff Code (Schedule B) | 4009310000 |
| UPC | 00072053052930 |
| VMRS Code | 042004014 |
| UNSPSC | 40142000 |
Part Interchanges
- Beck/Arnley 142-0108
- Beck/Arnley 142-4498
- Beck/Arnley 142-4696
- Beck/Arnley 142-4712
- Beck/Arnley 142-4837
- Beck/Arnley 142-5297
- Beck/Arnley 142-5362
- Beck/Arnley 142-5842
- Beck/Arnley 142-5928
- Beck/Arnley 142-5968
- Beck/Arnley 142-4506
- Motorcraft KM-1506
- Motorcraft KM-1498
- Motorcraft KM-1505
- Motorcraft KM-622
- Motorcraft KM-743
- Motorcraft KM-852
- Uniroyal MC81
- ACDelco 20064S
- Dayco 70846
- Dayco 846
- Dayco B70846
- BF Goodrich MH404
- Firestone 51311469
- Kohler 225338
- Carquest 20774
- Allis Chalmers 4295840
- Allis Chalmers 4335993
- Allis Chalmers 4348289
- Allis Chalmers 4862244
- Atlas (Canada) MH-3774
- British Leyland GRH265
- Carrier Transicold 580080000
- Carrier Transicold 580080001
- Continental Belt 60857
- Cummins 3275391
- Datsun/Nissan 2202547700
- Epton MH404
- Fiat 4343796
- Fiat 4365781
- Fiat 4227245
- Fiat 4248289
- Fiat 4385781
- Ford 74EB 8260 AC
- Ford D4RY 8260 A
- Ford D52E 8B274 DB
- Ford D5FZ 8260 B
- Ford D5FZ 8260 D
- Ford D5RY 8260 B
- Ford D5ZE 8B274 BB
- Ford E57A 8260 EA
- Ford E57A 8260 EB
- Ford E57A 8B273 FB
- Ford E57A 8B274 EC
- Ford E5TZ 8260 C
- Ford E5TZ 8260 E
- Ford E5TZ 8286 E
- Ford 70EG 8260 AA
- Ford C4JZ 8260 C
- Toyota 9091601066
- Toyota 1657154050
- Toyota 1657154090
- Toyota 1657154130
- Isuzu 894403174
- Isuzu 8944031740
- Saab 838287
- Lazorlite L34-1940
- Lazorlite L34-2637
- Ultralast C0774
- Vera 54-01863
- Vera 54-04534
- Goodyear 60857
- Goodyear 611
- Volvo GM Heavy Truck V1092066
- NAPA Belts/Hose 7537
- Durkee-Atwood MR972
- <Unknown> 476715
- Duralast B70846
GATES 20774 Cross Reference
We have 2 alternatives for the 20774 by GATES:
Fits Vehicles
- International 1854 (1987-1988)
- International 1754 (1986-1989)
- International 7100 (1990-1991)
- International S1854 (1988)
- International S1754 (1987-1989)
- International 4800 (1990-1991)
- International 4900 (1990-1991)
- Saab 99 (1972)
- Toyota Crown (1968-1970)
- Mercury Capri (1972-1974, 1976-1977)
- Toyota Pickup (1981-1987)
- Ford Ranger (1985-1987)
- Ford Bronco II (1985)
- Isuzu Impulse (1985-1989)
- Triumph Spitfire (1975-1979)
- Fiat 131 (1975-1978)
- Fiat Brava (1980-1981)
- Fiat 124 (1970-1973, 1975-1979)
