(888) 312-8812 Login SignupGATES 1560 Truflex FHP Low Horse-Power V-Belt
Tap to view 2 more
$1599
Limited availability at this price!
In Stock
Get it by Thursday, Jun 11
GATES 1560 Part Description
Manufacturer
Product Description
Truflex FHP Low Horse-Power V-Belt
Features & Benefits
- Flex-bonded cords are strongly forged to the belt body, resulting in equal load distribution, resistance to fatigue and shock loads and the absorption of bending stress without cord deterioration
- Proprietary Flex-Weave cover is a patented fabric construction, providing extended protection to the belt core from oil, contaminants and heat for longer belt life
- Runs with smooth, quiet operation
- Meets RMA oil and heat-resistant standards and static conductivity requirements
- Available in 2L (0), 3L (1), 4L (2) and 5L (3) cross-sections
- Do not use on applications where FHP medium horsepower V-belts are recommended
GATES 1560 Specifications
Product Attributes
| Type | FHP Low Horse-Power V-Belt |
| Cross Section Designation | 3L |
| Angle | 38 |
| Strand Quantity | 1 |
| Top Width | .38 in |
| Outside Circumference | 56 in |
| Effective Length | 55.68 in |
| Construction | Wrapped |
| Notched | No |
| Belt Material | EPDM |
| Cord Material | Polyester |
| Top Width | 10 mm |
| Outside Circumference | 1422 mm |
| Effective Length | 1414 mm |
Additional Information
| Harmonized Tariff Code (Schedule B) | 4010323000 |
| Country of Origin (Primary) | MX |
| Stock Status | S |
| UPC | 00072053001938 |
| VMRS Code | 065005003 |
| UNSPSC | 26111801 |
GATES 1560 Cross References
| Brand | Part Number |
|---|---|
| <Unknown> | 2C318, 3920, 42505316, KK5705475AR36, P81206 |
| ACDelco | 3L560 |
| American Lincoln | 20002103 |
| Browning Manufacturing | 0545 |
| CARQUEST | 1560 |
| CONTINENTAL AG | 3L560 |
| Dayco | 0M056, 3L560 |
| Gilmer | 2560 |
| Goodyear | 3L560, 73560 |
| Grainger | 3L560 |
| Harding Bros | VB507 |
| Jacobsen | 09360A |
| L Series | 3L560 |
| Maytag | 311013, 3110166 |
| Metric | 9R1420 |
| Mopar | B3L-560 |
| NAPA Belts/Hose | 3L560 |
| Power Lawnmower Part | 109-047 |
| Reliance Electric | 108191 |
| Sunbrand | 1560T702 |
| Universal Sewing | 18239 |
| Whirlpool | 234806 |
