(888) 312-8812 Login SignupFRAM PH6355 Spin-on Combination By-Pass Oil Filter
Tap to view 2 more
Special Order Item
Call us at (888) 312-8812
Speak with a customer service representative who can quote the price over the phone.
FRAM PH6355 Part Description
Manufacturer
Product Description
FRAM, PH6355, Oil Filter
Features & Benefits
- Proven protection for up to 10,000 miles (16,000 kilometers)
- Engineered for use with synthetic or conventional motor oils
- Filter media is a blend of fiber and resin that captures 95% of the dirt particles
- Silicone anti-drain back valve helps ensure safe engine start up
Spin-on Combination By-Pass Oil Filter
FRAM PH6355 Specifications
Product Attributes
| Filter Media Material | Cellulose/Synthetic Blend |
| Height | 5.039 IN |
| Anti-Drain Back Valve | Yes |
| Bypass Relief Valve Setting | 20 PS |
| Bypass Relief Valve | Yes |
| Filter Type | Spin-On Canister |
| Gasket Thickness | 0.394 IN |
| Housing Color | White |
| Non Slip Grip | No |
| Torque Nut | No |
| Gasket Inside Diameter | 2.559 IN |
| Gasket Outside Diameter | 2.953 IN |
| Gasket Type | O-Ring |
| Attachment Type | Spin-On |
| Burst Pressure | 350.000 PS |
| Gasket Type | Base |
| Grade | Advanced |
| Grade Type | Regular |
| Inlet Type | Threaded |
| Inside Thread Diameter | M26x1.5 MM |
| Meets Or Exceeds Original Equipment Manufacturer Specifications | Yes |
| New Or Remanufactured | New |
| Outside Diameter | 3.969 IN |
| Replacable Filter | Yes |
| Reusable | No |
| Thread Size | Metric |
| Burst Pressure | 350.000 PS |
Additional Information
| Country of Origin (Primary) | CN |
| Harmonized Tariff Code (HTS) | 8421230000 |
| Warranty Special | See Rep |
| Warranty Special UOM | SR |
| Warranty Time | 30 |
| Warranty Time UOM | DA |
| UPC | 00009100381590 |
| UNSPSC | 15121501 |
FRAM PH6355 Part Interchanges
| Brand | Part Number |
|---|---|
| Donaldson | P551343 |
| Motorcraft | FL-805 |
| Hastings | LF147 |
| Group 7 | L34750 |
| ACDelco | PF2147 |
| Kralinator | D3 |
| Purolator | L34750 |
| Quaker State | L34750 |
| Wix | 51067 |
| Big A | 92067 |
| Baldwin | BD28 |
| LUBER-FINER | LFP805, LFP9930 |
| Carquest | 85067 |
| Shell - Archived | L34750 |
| Mann-Filter | WP928/81 |
| Chrysler | MD069782 |
| Crosland | 2087 |
| Fleetguard | LF3564 |
| Mitsubishi | MD069782, MD184086 |
| Valvoline | VO-136 |
| STP | LFP805 |
| NAPA | 1067 |
| FVP | R1067 |
| Mobil | L34750 |
| Car Care | OF6355 |
| Mighty Distributing System | L34750 |
| Factory Motor Parts | R1067 |
| STP Filters | LFP805 |
FRAM PH6355 Fits Vehicles
- Ford Ranger (1985-1987)
FRAM PH6355 Cross References
We have 9 alternatives for the PH6355 by FRAM:
