(888) 312-8812 Login Signup| Type | Bellows # | Top Plate # | Bottom Plate # | Bottom Plate Material | |
|---|---|---|---|---|---|
| Double Convoluted | 233D2 6412 FD53035 | --- |
| Top Plate Dia. (in) | Design Height (in) | Min. Height (in) | Max. Height (in) |
|---|---|---|---|
| 11.31 | 11.0 | 4.6 | 15.4 |
| Max. Diameter (in) | Load (lbs) @ 80psi | Load (lbs) @ 100psi | Natural Frequency (cpm) |
| 16.0 | 7930 | 9910 | 84 |
| OEM # - Xref # | Manufacturer |
|---|---|
| 1003587781C | Ridewell |
| AS7781 | Firestone |
| FD53035545 | ContiTech |
| FS7781 | Firestone |
| RL77810 | Road Leveler |
| W013587781 | Firestone |
| Brand | Part Number |
|---|---|
| CONTITECH | FD53035545 |
| FIRESTONE | AS7781, FS7781, W013587781 |
| RIDEWELL | 1003587781C |
| ROAD LEVELER | RL77810 |
Be the first to review this product!
Since 1919, Triangle Suspension Systems Co.® has set the gold standard for steel leaf springs. With generations of spring shop customers going back for more than 7 decades, Triangle Suspension has made a name for itself for its use of high-quality materials that are backed by ISO-compliant manufacturing processes. Their catalog covers a wide range of applications, including leaf spring assemblies, air beams, and helper springs for light, medium, and heavy duty vehicles. They also offer spring repair components and custom-engineered spring to fill almost any niche. All their products are manufactured in-house in their DuBois, PA, manufacturing facility and distributed across the United States and beyond.
