WABCO 9254600320 - Air Brake Spring Brake Cylinder Assembly - Tristop-Cylinder Disc G-20/24
$62199
14 day lead time
. Learn more
WABCO part description
Product Attributes
| Max. operating pressure | 10.2/8.5 bar |
| Calculated Volume (dm³) | 14.3354 |
| Distance between bolts | 120.6 mm |
| Size | 377 x 195 x 195 |
| Push-Rod Length | 15 mm |
| Release Pressure | 5.1 bar |
| Type Of Operation | Disc |
| Port threads | M16 x 1.5 |
| Temperature Range | -40°C to +80°C |
| Bolt Threads | M16 x 1.5 |
| Bolt Lengths | 43.0 mm |
| Port thread 11 | M16 x 1.5 |
| Type | 20/24 |
| Weight | 17.335 |
| Output Force M | 9940 N |
| Return-Spring Force | 220 N |
| Push-rod thread | Ball R8 |
| Total Length | 252.0 mm |
| Port thread 12 | M16 x 1.5 |
| Stroke | 57/57 mm |
WABCO 9254600320 Cross Reference
We have 3 alternatives for the 9254600320 by WABCO:
Whether it’s for cars, buses, trucks, or trailers, WABCO® is at the frontline at developing and providing products and systems to make vehicles safer and easier to control. Founded in 1869, WABCO is a major supplier of braking, stability, suspension and transmissions in the Americas and beyond. The company is recognized as introducing the modern air brake system in 1869, and continues to lead the industry in air brake design and production for the heavy duty and commercial vehicle sectors. Today, WABCO operates as a division of the German auto parts maker ZF and employs 16,000 employees in facilities in 36 countries worldwide.
