(888) 312-8812 Login SignupWABCO 4640070010 Suspension Self-Leveling Valve
Tap to view 3 more
No Stock Available
We cannot fulfill orders for this part at this time. Please check back later or request a stock notification to receive an email.
We may have similar parts for sale. Search Alternatives >
WABCO 4640070010 Part Description
WABCO 4640070010 Specifications
Product Attributes
| Stroke Of Lever | ±30° |
| Weight | 0.46517 |
| Calculated Volume (dm³) | 0.489 |
| Mounting | 2x Ø 8.5 mm |
| Max. operating pressure | 159.5 psi |
| Actuation Angle | -19° to +19° |
| Size | 65 x 215 x 35 |
| Port thread 1 | Quick Connection Ø 0.24 in |
| Length | R 201 mm |
| Type | With Lever |
| Version | With one-way valve |
| Distance Between Holes | 46.4 mm |
| Type Of Operation | Hole-lever Ø 6.5 mm |
| Port thread 2 | Quick Connection Ø 0.24 in |
| Temperature Range | -40°C to +80°C |
WABCO 4640070010 Cross References
We have 30 alternatives for the 4640070010 by WABCO:
- RENAULT 5021170189
- 5010136105
- DAF 1505081
- 759050
- IVECO 08188642
- KOGEL 332419
- MAN 81436106129
- CNHTC WG1642440051/1
- DAF 0759050
- CNHTC WG16424400511
- DAF 759050
- DEUTZ 4432191
- DEUTZ 04432191
- ERF 4134534
- FAW 5001075CA01C00B
- FAW 5001320Q824A
- FAW 5001075CA01A
- FORD 3C465C100AA
- IRISBUS 8188642
- IVECO 8188642
- IVECO 81436106129
- KÖGEL 332419
- MAN 4134534
- MAN 8188642
- NEOPLAN 81436106129
- PACCAR 1505081
- RENAULT 5010136105
- SCANIA 1934938
- SHAANXI 81436106129
- TATRA 4640070010
WABCO 4640070010 Manufacturer Information
Whether it’s for cars, buses, trucks, or trailers, WABCO® is at the frontline at developing and providing products and systems to make vehicles safer and easier to control. Founded in 1869, WABCO is a major supplier of braking, stability, suspension and transmissions in the Americas and beyond. The company is recognized as introducing the modern air brake system in 1869, and continues to lead the industry in air brake design and production for the heavy duty and commercial vehicle sectors. Today, WABCO operates as a division of the German auto parts maker ZF and employs 16,000 employees in facilities in 36 countries worldwide.
