Centric 122.35000 - Centric Premium Brake Drum
$3899
In stock
limited availability at this price!
Pay over 3-12 months with
. Learn more
. Learn more
CENTRIC part description
Product Description
Centric Premium Brake Drum
Features & Benefits
- OE style castings ensure superior performance and extended service life. Machined finishes provide cleaner appearance through wheels. Precision machined friction surfaces ensure smooth operation and reduced noise
Product Attributes
| Weight [cntrc] Kgs | 3.182 |
| Weight [cntrc] Lbs | 7.000 |
| Mounting Type [cntrc] | Floating |
| Bolt Circle Diameter [cntrc] Mm | 112.000 |
| Bolt Circle Diameter [cntrc] In | 4.409 |
| Hub Hole / Register [cntrc] Mm | 58.000 |
| Hub Hole / Register [cntrc] In | 2.283 |
| Height [cntrc] Mm | 59.000 |
| Height [cntrc] In | 2.323 |
| Friction Surface Width [cntrc] Mm | 39.500 |
| Friction Surface Width [cntrc] In | 1.555 |
| Product Grade [cntrc] | Premium |
| Maximum Brake Diameter (Discard) | 204.000 MM |
| Maximum Brake Diameter (Discard) | 8.031 IN |
| Outside Diameter | 235.100 MM |
| Outside Diameter | 9.256 IN |
| Outer Cooling Fins | No |
| Mounting Hole Diameter | 12.700 MM |
| Mounting Hole Diameter | 0.500 IN |
| Nominal Drum Diameter | 202.900 MM |
| Nominal Drum Diameter | 7.988 IN |
Additional Information
| Harmonized Tariff Code (HTS) | 8708305030 |
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | CN |
| Harmonized Tariff Code (Schedule B) | 8708300050 |
| UPC | 805890490593 |
Part Interchanges
CENTRIC 122.35000 Cross Reference
We have 1 alternatives for the 122.35000 by CENTRIC:
Fits Vehicles
- Smart Roadster (2004-2005)
- Smart Crossblade (2004)
- Smart Fortwo (2005-2015)
