Standard Ignition UF-343 - Distributorless Coil
- Part Number
- UF-343
- Manufacturer
- STANDARD IGNITION
- Description
-
Distributorless Coil
details
$22299
MSRP: $505.49
Save: $282.50
In stock
limited availability at this price!
Pay over 3-12 months with
. Learn more
. Learn more
STANDARD IGNITION part description
Product Description
Distributorless Coil
Features & Benefits
- Our ignition coils use 100% pure copper windings in the primary and secondary bobbins to improve durability and provide higher resistance to internal shorts and dielectric breakdown
- Our premium ignition coils consist of a special blended formula for the best performance, longest life and better heat dissipation
- A full E-Lam core of silicon steel and solid brass high voltage terminals protects against corrosion. Our ignition coils are built for maximum output voltage
- Primary and Secondary windings feature enamel magnet wire for the highest temperature rating in the aftermarket
- As a tier I manufacturer with engineering and design capabilities second to none, our ignition coils are made to the highest quality standards
- As a global manufacturer of original equipment ignition products, we maintain complete quality control throughout the manufacturing process from componentry to finished product
Product Attributes
| Voltage | 12 |
| Color | Black |
| Mounting Position | Distributorless |
| Ignition Type | Distributorless |
| Terminal Type | Blade |
| Mounting Hardware Included | No |
| Connector Shape | Rectangular |
| Mount Type | Bolt On |
| Terminal Quantity | 8 |
| Terminal Gender | Male |
| Mounting Bracket Included | Yes |
| Coil Included | Yes |
| Connector Gender | Female; Female |
| Connector Quantity | 2 |
| Contents | Ignition Coil |
| Grease Pack | No |
| Instructions Included | No |
Additional Information
| Country of Origin (Primary) | CN |
| Harmonized Tariff Code (HTS) | 8511300080 |
| Warranty Distance | 36000 |
| Warranty Distance UOM | MI |
| Warranty Time | 36 |
| Warranty Time UOM | MO |
| UPC | 00091769584764 |
Part Interchanges
- Beck/Arnley 178-8492
- Delphi GN10620
- Echlin IC259
- Kem E5126
- NGK 48956
- NGK U3032
- Spectra Premium C-852
- ACDelco 88921398
- ACDelco E570A
- Motorad 3IC315
- Autopart International 2505-311082
- BWD E752
- Duralast C1186
- Mazda BP4W1810X
- Mazda BP4W1810XA
- Mazda BP4W1810XB
- Mazda BP4W1810XB9U
- Airtex 5C1204
- Import Direct 23-0405
- BWD Intermotor E752
- CARQUEST Premium By WELLS 55-1660
- HOLSTEIN 2IGC0367
- Carquest Premium Vehicle Solutions EBE1743
- 920-1091
- CUF343
Fits Vehicles
- Mazda Miata (1999-2000)
