(888) 312-8812 Login SignupDELPHI ES20103 Oxygen Sensor
$14199
Limited availability at this price!
5 Day Lead Time
Get it by Wednesday, Jul 15
DELPHI ES20103 Part Description
Manufacturer
Product Description
Oxygen Sensor
Features & Benefits
- Delphi planar technology covers older, conical design sensors
- Smart design consolidates SKUs without using long wires
- Patented protective sensor coating helps prevent contamination
- Validated for all fuel types, including ethanol blends like E85
- OE tested to 150,000 miles, plus 2,000 hours severe thermal testing
- Delphi is a global OE manufacturer for oxygen sensor and all oxygen sensors are built to Delphi's OE standards
DELPHI ES20103 Specifications
Product Attributes
| Package Contents | Oxygen Sensor, Instruction Sheet |
| Position(s) | Front, Rear, Rear Left, Rear Right. For the position specific to your vehicle, refer to the Applications. |
| Wiring Harness Length | 20.1 IN |
| Wiring Harness Length | 510.0 MM |
| Sensor Type | Narrow-Band |
| Terminal Type | Bullet |
| Universal Or Specific Fit | Specific |
| Band Type | Narrow |
| Wire Quantity | 4 |
| Grade Type | Standard Replacement |
| Connector Shape | Square |
| Terminal Quantity | 4 |
| Connector Gender | Male |
| Terminal Gender | Male |
| Thread Diameter | 0.7 IN |
| Wrench Size | 22mm |
| Thread Size | M18 - 1.5 |
| Overall Length | 21.3 IN |
| Overall Length | 540.0 MM |
| Mounting Type | Threaded |
| Thread Diameter | 18.0 MM |
| Wire Gauge Measurement | 20.0 GU |
| Thread Type Standard | Metric |
| Heated | Yes |
Additional Information
| Harmonized Tariff Code (HTS) | 9027102000 |
| Warranty Distance UOM | DH |
| Warranty Distance | 12000 |
| Harmonized Tariff Code (Schedule B) | 9027100000 |
| Warranty Time UOM | MO |
| Warranty Time | 12 |
| Country of Origin (Primary) | CN |
| UPC | 00689604145197 |
| VMRS Code | 045021011 |
| UNSPSC | 41111924 |
DELPHI ES20103 Cross References
| Brand | Part Number |
|---|---|
| ACDelco | 2131198, 2131199, 2131204, 2131394, 2131483, 2131484, 2131507 |
| BorgWarner | OS1241, OS1502, OS1555, OS1573, OS1576, OS1601, OS2152, OS703, OS935, OS959 |
| Bosch | 13188, 13556, 13623, 13908, 15215, 15273, 15275, 15276, 15289, 13353, 15687 |
| DENSO | 234-4623, 234-4069, 234-4558 |
| DENSO Auto Parts | 234-4069, 234-4623 |
| General Motors | 88971387 |
| Kem | 138-659, 138-693 |
| N/A | 2344069, 2344623, 138659, 138693, 8946501090, 8946514230, 8946530190, 8946530360, 8946530790, 8946530800, 8946533030, 8946547060, 8946552060, 8946552120, 8946552200, 8946552280, 8946552430, 8946552500 |
| NTK | 24294, 24579 |
| Oextra | REA1050, REA1079 |
| SPECTRA PREMIUM | OS5217 |
| Standard Motor Products | SG1319, SG391, SG748, SG795, SG801, SG819, SG822, SG847, SG358 |
| Toyota | 89465-01090, 89465-14230, 89465-30190, 89465-30360, 89465-30790, 89465-30800, 89465-33030, 89465-47060, 89465-52060, 89465-52120, 89465-52200, 89465-52280, 89465-52430, 89465-52500 |
| Walker Products | 25024298 |
| Wells | SU1533, SU4807, SU4871, SU4872, SU4882, SU5665, SU5682, SU6261 |
DELPHI ES20103 Fits Vehicles
- Lexus GS460 (2008-2011)
- Scion xD (2008-2014)
- Toyota Yaris (2007-2011)
- Scion xB (2004-2006)
- Scion xA (2004-2006)
- Toyota Supra (1998)
- Toyota Prius (2001-2003)
- Toyota Matrix (2003-2006)
- Toyota Echo (2000-2005)
- Toyota Camry (1992-1996)
- Lexus GS300 (1993-1997)
- Lexus ES300 (1992-1996)
- Pontiac Vibe (2003-2006)
