DONALDSON part description

Product Description

AIR CLEANER, ECG 2500

Product Attributes

Body Diameter Maximum 11.00 in
Body Length 21.25 in
Inlet Diameter 7.00 in
Outlet Diameter 7.00 in
Overall Length 24.32 in
Rated Flow Hr 45.3 m³/min (1600 cfm)
Rated Flow Lr 34 m³/min (1201 cfm)
Rated Flow Mr 39.6 m³/min (1398 cfm)
Restriction Hr 10.00 in H2O
Restriction Lr 5.98 in H2O
Restriction Mr 7.99 in H2O
For more than 100 years, Donaldson® has provided effective solutions to complex filtration challenges in various industries. Fleet managers worldwide have relied on Donaldson’s wide range of filtration products to ensure their trucks operate at peak efficiency and reduce expenses and maintenance downtime in the long run. These products include air intake filters and cleaners, cabin air filters, coolant filters, fuel filters and water separators, transmission filters, exhaust filtration products, and so much more. Each Donaldson filtration product is engineered for durability and performance that matches that of the original. Whether they are long-haul trucks, school buses, dump trucks, or other commercial vehicles, Donaldson filtration products will help keep them running smoothly.
