BENDIX 222246N Part Description
Manufacturer
Product Description
Rotochamber
Features & Benefits
- A service new air brake chamber (disc) that’s built to offer an extended lifespan at a competitive price
- Made using premium-quality materials to ensure superior durability
- Engineered in a state-of-the-art facility to meet the strictest quality standards
- Tested to ensure trouble-free installation and operation
Courtesy of Bendix – All rights reserved
Bendix TYP-24 Air Brake Chamber
The Bendix TYP-24 air brake chamber is a critical air brake component designed to convert the energy of air pressure into mechanical force to apply the brakes and stop the vehicle. This is made following a stringent manufacturing process to ensure each Bendix rotochamber provides maximum performance and guaranteed efficiency.
BENDIX 222246N Specifications
Product Attributes
| Gross Weight | 6.520 KG |
| Market Indicator | Aftermarket New |
| Net Weight | 6.520 KG |
| Chamber Diameter | A~ 6.41 IN |
| Clevis / Yoke Arm Bushing Pin Diameter | A~ .50 IN (A~ 12.7 MM) |
| Clevis / Yoke Style | Threaded (Standard) |
| Cover Threads (for Breather) | Not applicable to this part |
| Cover Threads (for Warning Switch) | Not applicable to this part |
| Front Mounting Bracket | Not applicable to this part |
| Port Size | 1/4-18 NPT |
| Product Type | Type 24 |
| Push Rod Length (to Yoke Pin Center when Applicable) [IN] | 4.00 in |
| Push Rod Thread / Style | 1/2-20 UNF-2A |
| Rear Mounting Bracket | Not applicable to this part |
| Stroke | 2.50 IN (63.5 MM) |
| Stud Length | 1.75 IN (44.5 MM) |
| Stud Spacing | 4.75 IN (120.7 MM) |
| Stud Thread Size | 5/8-18 UNF-3A |
Additional Information
| Country of Origin (Primary) | US |
| Harmonized Tariff Code (HTS) | 8412310080 |
| UPC | 04068078335123 |
| VMRS Code | 013010034 |
