DANA 5-1-873-1 - Drive Shaft Companion Flange
We cannot fulfill orders for this part at this time. Please check back later or request a stock notification to receive an email.
Sometimes we may have similar parts for sale, click the button below to see if anything matches.
DANA part description
California Proposition 65 Warning
Product Attributes
Series | 1610 |
Material | Steel |
NUMBER OF HOLES | 8 |
Pilot Diameter (C) In. | 6.625 - FEMALE IN |
Bolt Circle Diameter (B) In. | 6.130 IN |
FLANGE TYPE | Circular |
Actual Hole Diameter (Max) | 2.001 IN |
Actual Hole Diameter (Min) | 2.000 IN |
Bore Diameter (D) In. | 2.000 IN |
Circ Flnge Face To End Of Hub | 3.500 IN |
Flange Width Diameter (A) In. | 6.88 IN |
Hub Diameter (E) In. | 5.250 IN |
Key Width (K) In. | 0.500 IN |
Set Screw Hole Diameter In. | 0.500 IN |
Bolt Hole Diameter (In.) | .375 - DRILLED IN |
Additional Information
Country of Origin (Primary) | US |
UPC | 00023913224219 |
VMRS Code | 024002040 |
Part Interchanges
- Neapco OE Series N5-1-873-1
- Ingersoll Rand 82147455
- Daimler Truck North America SP 5 1 873 1HP
- Dana Commercial Vehicle Service Parts 1610-2000-500
- Dana Commercial Vehicle Service Parts 2104-518731
- Dresser 82147455
- Volvo 2104-518731
- Volvo SP 518731
- International Harvester (IHC) 518731
- International Harvester (IHC) D518731
- International Harvester (IHC) E518731
- Navistar 518731
- Navistar D518731
- Navistar DS518731
- Navistar E518731
- Mack 2104-518731
- Freightliner SP 5 1 873 1HP
- UAP 5-1-873-1
