Name: Dana 5011802 DRIVE SHAFT END YOKE
SKU: 5011802
Price: 76.49 USD
Availability: InStock

DANA part description

California Proposition 65 Warning

WARNING: This product can expose you to chemical which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information, go to www.P65Warnings.ca.gov. (Read more)

END YOKE RD. HOLE - Series 704

Special Note: Lead Time90 Days

Product Attributes

Series	1310
Material	Steel
Type	Straight Round Hole
Hole Diameter (In) P	1.500 IN
Hub Diameter R	2.125 IN
Length Thru Hole Q	1.125 IN
Yoke Bearing Dimension (In) D	1.062 IN
Keyway Location W	12
Sae Keyway Width (In) X	0.375 IN
Set Screw Location W	9
C/L To End Hub S	5.562 IN
Set Screw Hole Diameter (In)	0.375 IN
Hole Diameter - Max	1.5005 IN
Hole Diameter - Min	1.4995 IN
Keyway Width - Max	0.375 IN
Keyway Width - Min	0.376 IN
