(888) 312-8812 Login SignupRAYBESTOS 780870R Raybestos R-Line Brake Rotor
MSRP: $189.17
$17249
Save $16.68
Limited availability at this price!
In Stock
Get it by Thursday, Jul 30
RAYBESTOS 780870R Part Description
Manufacturer
Product Description
Raybestos R-Line Brake Rotor
Application Summary
2021-2011 Jeep Grand Cherokee Front, 2022-2011 Dodge Durango Front, 2022 Jeep Grand Cherokee WK Front
Features & Benefits
- OE Fit, Form, and Function
- Developed from OE samples and made with G3000-qualified material, ensuring OE fit, form and function for dependable braking.
- SAE Standard
- R-Line Rotors meet the SAE standard for tensile strength, providing structural integrity and a maximum service life.
- Low Initial Lateral Runout and Thickness Variation
- R-Line Rotors have a small parameter lateral runout and a thickness variation ensuring less pedal pulsation, less brake noise, and an extended pad life.
- Mill Balanced Edges
- R-Line Rotors are mill balanced and 100 percent validated. This helps minimize the thickness variation on the rotor and leads to minimized vibration and smoother stopping.
RAYBESTOS 780870R Specifications
Product Attributes
| ABS Tone Ring Included | No |
| Center Hole Diameter | 2.84 IN |
| Center Hole Diameter | 72.15 MM |
| Conventional Or Drum-In-Hat Type Rotor | Conventional |
| Directional or Non-Directional Brake Surface | Non-Directional |
| Discard Thickness | 1.201 IN |
| Discard Thickness | 30.5 MM |
| Harmonize Code | 8708.30.5030 |
| Inside Diameter | 8.78 IN |
| Inside Diameter | 223 MM |
| Material | Cast Iron |
| Mounting Bolt Hole Circle Diameter | 5 IN |
| Mounting Bolt Hole Circle Diameter | 127 MM |
| Mounting Bolt Hole Diameter | 0.667 IN |
| Mounting Bolt Hole Diameter | 16.95 MM |
| Mounting Bolt Hole Quantity | 5 |
| Nominal Thickness | 1.26 IN |
| Nominal Thickness | 32 MM |
| Outside Diameter | 13.78 IN |
| Outside Diameter | 350 MM |
| Overall Height | 2.15 IN |
| Overall Height | 54.6 MM |
| Salability Restrictions | No |
| Solid Or Vented Type Rotor | Vented |
| Stud/Lug Hole Quantity | 5 |
| Surface Type | Smooth |
| UNSPSC Code | 25171715 |
Additional Information
| Country of Origin (Primary) | CN |
| Canadian Harmonizing Tariff Code | 8708309990 |
| Harmonized Tariff Code (HTS) | 8708305030 |
| UPC | 00829352847152 |
RAYBESTOS 780870R Cross References
| Brand | Part Number |
|---|---|
| ADVANCE AUTO PARTS | 321092, YH321092, YH321092C, YH321092P |
| AUTOPARTSOURCE | 491395 |
| AUTOXTRA | AX900946 |
| AUTOZONE | 72112, 72112DG, 72112GT, 72150DG, 72150DL |
| Advance Auto Parts | G09507SD |
| Autoxtra | AX900946P |
| BENDIX | PRT6100 |
| BOSCH | 16011492 |
| BRAKEBEST | 780870, 780870FZN, 780870PER, 780870R, 780870RGS |
| Brembo | 09.N236.21, 09.N236.2X |
| CENTRIC | 120.58008, 120.58008CRY, 121.58008, 126.58008CSL, 126.58008CSR, 126.58008SL, 126.58008SR, 127.58008L, 127.58008R, 128.58008CL, 128.58008CR, 128.58008L, 128.58008R, 320.58008 |
| CHRYSLER | 68035012AB, 68035012AC, 68035012AD, 68035012AE, 68240046AA, 68240046AB |
| Centric Parts | 120.58008, 120.58008CRY, 121.58008, 126.58008CSL, 126.58008CSR, 126.58008SL, 126.58008SR, 127.58008L, 127.58008R, 128.58008CL, 128.58008CR, 128.58008L, 128.58008R, 320.58008 |
| Chrysler | 4755569AA, 4755577AA |
| DURA CORP | BR53064, BR900946 |
| Dodge | 04755569AA, 04755577AA |
| DuraGo | BR900946, BR90094602, BR900946-02, BR900946-03 |
| Dynamic Friction Company | 60042007, 60442007 |
| MAGMA PRODUCTS | PMR145197 |
| NAPA BRAKES | SDK6710 |
| NEWTEK AUTOMOTIVE | 53064 |
| Newtek Automotive USA | 53064 |
| POWERSTOP | AR83078EVC |
| PROMAX | 14-53064 |
| Parts Master | 900946 |
| PowerStop | AR83078 |
| QUALIS | 43175 |
| TopNotch | TN780870GEO |
| UAP | 2053064, 53064 |
| Ultra Brake | 51215 |
| WINHERE | 6621295 |
| WORLDPAC | 1407-321092, 1427-731812 |
| WORLDPARTS | WS1-153064 |
| Wagner Brake | BD180434E, BD180753E |
| Winhere | 6622974 |
RAYBESTOS 780870R Fits Vehicles
- Jeep Grand Cherokee WK (2022)
- Dodge Durango (2011-2025)
- Jeep Grand Cherokee (2011-2021)
