RAYBESTOS 980593 Raybestos Specialty - Truck Brake Rotor

★★★★★ (0)
980593 by RAYBESTOS - Raybestos Specialty - Truck Brake Rotor
RAYBESTOS

$99.49

Limited availability at this price!

1 Day Lead Time

Get it by Thursday, Jul 2
No Hassle Return Policy Details
Free Economy shipping on orders over $499 details
Orders placed over the weekend will be processed the next business day.

RAYBESTOS 980593 Part Description

Manufacturer

RAYBESTOS

Product Description

Raybestos Specialty - Truck Brake Rotor

Application Summary

2018-2007 BMW X5 Rear, 2019-2009 BMW X6 Rear

Features & Benefits

  • OE Fit, Form, and Function
  • Our vehicle-specific design matches OE fit, form and function, providing ultimate strength and performance
  • Cooling Vanes
  • We dedicate time to match the cooling vanes on our Specialty rotors to OE designs, ensuring: Optimal cooling Reduced fade Less noise Increased pad life
  • Coating
  • All Specialty rotors are protected against the elements. All new Specialty rotors come fully coated with Grey Fusion 4.0® rated at 300 hrs. salt spray or a Black Fusion painted hat and edge for rust protection.
  • All Specialty rotors are protected against the elements. All new Specialty rotors come fully coated with Grey Fusion 4.0(R) rated at 300 hrs. salt spray or a Black Fusion painted hat and edge for rust protection.
  • SAE Standard for Tensile Strength
  • Our rotors follow SAE standards for tensile strength, hardness, and iron grade, providing structural integrity and maximum service life
  • Turned Finish
  • A turned finish provides an excellent surface for the pads to engage with to ensure a smooth and effective stop right out of the box

RAYBESTOS 980593 Specifications

Product Attributes

ABS Tone Ring Included No
Center Hole Diameter 2.953 IN
Center Hole Diameter 75 MM
Conventional Or Drum-In-Hat Type Rotor Drum-In-Hat
Discard Thickness 0.724 IN
Discard Thickness 18.4 MM
Harmonize Code 8708.30.5030
Inside Diameter 8.346 IN
Inside Diameter 212 MM
Mounting Bolt Hole Circle Diameter 4.724 IN
Mounting Bolt Hole Circle Diameter 120 MM
Mounting Bolt Hole Diameter 0.645 IN
Mounting Bolt Hole Diameter 16.4 MM
Mounting Bolt Hole Quantity 5
Nominal Thickness 0.787 IN
Nominal Thickness 20 MM
Outside Diameter 12.591 IN
Outside Diameter 319.8 MM
Overall Height 3.079 IN
Overall Height 78.2 MM
Salability Restrictions No
Solid Or Vented Type Rotor Vented
Stud/Lug Hole Quantity 5
Surface Type Smooth
UNSPSC Code 25171715

Additional Information

Country of Origin (Primary) CN
Canadian Harmonizing Tariff Code 8708309990
Harmonized Tariff Code (HTS) 8708305030
UPC 00829352822777

RAYBESTOS 980593 Cross References

BrandPart Number
ADVANCE AUTO PARTSYH200732, YH200732P
ATE BRAKE PRODUCTS420206, SP00016
AUTOXTRAAX900938
AUTOZONE45522, 45522DG, 73022
AutoZone73023
AutoxtraAX900938P
BECK/ARNLEY083-3400
BENDIXPRT6091
BMW34216771970, 34216793247, 34216868940, 34216886479
BOSCH15010134
BRAKEBEST15010114, 15010134, 921169RGS, 980593, 980593FZN, 980593R, 980593RGS
Brembo09.9925.11, 09.9925.1S, 09.9925.1X
CENTRIC120.34097, 120.34121, 121.34095, 121.34097, 121.34121, 125.34095, 125.34097, 125.34097CRY, 125.34121, 126.34095SL, 126.34095SR, 126.34097CSL, 126.34097CSR, 126.34097SL, 126.34097SR, 126.34121SL, 126.34121SR, 127.34095CL, 127.34095CR, 127.34095L, 127.34095R, 127.34097CL, 127.34097CR, 127.34097L, 127.34097R, 127.34121L, 127.34121R, 128.34095CL, 128.34095CR, 128.34095L, 128.34095R, 128.34097CL, 128.34097CR, 128.34097L, 128.34097R, 128.34121L, 128.34121R, 320.34095H, 320.34097, 320.34097H
Centric Parts120.34097, 120.34121, 121.34095, 121.34097, 121.34121, 125.34095, 125.34097, 125.34097CRY, 125.34121, 126.34095SL, 126.34095SR, 126.34097CSL, 126.34097CSR, 126.34097SL, 126.34097SR, 126.34121SL, 126.34121SR, 127.34095CL, 127.34095CR, 127.34095L, 127.34095R, 127.34097CL, 127.34097CR, 127.34097L, 127.34097R, 127.34121L, 127.34121R, 128.34095CL, 128.34095CR, 128.34095L, 128.34095R, 128.34097CL, 128.34097CR, 128.34097L, 128.34097R, 128.34121L, 128.34121R, 320.34095H, 320.34097, 320.34097H
DURA CORPBR34363, BR900938, BR900940
DuraGo900938, BR900938
Dynamic Friction Company604-31143, 604-31148
MAGMA PRODUCTSPSR125116
NAPA BRAKESSDK6552
NEOTEK106658GF, 106669GF
NEWTEK AUTOMOTIVE34363, R940
Newtek Automotive USA34363, R940
PAGID355114002
PAGID Racing355114002
POWERSTOPEBR1031EVC
PROMAX14-34363
PRONTOBR900938
Qualis45522
TRW4854
TopNotchTN980593GEO
UAPR34095, R34097
VAICOV2080094
WAGNER BRAKEBD180059, BD180059E, BD180061
WINHERE6621040
WORLDPAC1407-75286, 1427-530119
Winhere6621169

RAYBESTOS 980593 Fits Vehicles

  • BMW X6 (2009-2019)
  • BMW X5 (2007-2018)
