PETERSON LIGHTING 850R-1 Part Description
Manufacturer
Product Description
LED STOP/TURN/TAIL, RECTANGULAR, ECE, & DOT 11.8" LEADS, 5.3"X3.44" MV
Features & Benefits
- 850R-1 has hardwired 11.8" (300mm) stripped leads.
- 850R-1P has hardwired 11.8" (300mm) leads with PL3 plug.
- Also fits surface-mount cluster pods. See Peterson LED Catalog page 98.
- Certified to meet both FMVSS 108 (USA) & ECE (European) requirements in horizontal or vertical position.
- Certified to meet IP67 ingress protection rating.
- Grommet fits material up to 6 mm.
- Multi-volt design compatible with 12 & 24 volt systems.
- See matching backup light on Peterson LED Catalog page 49.
- See matching turn signal light on Peterson LED Catalog page 17.
- Stop / Turn / Tail Light, Hardwired
rubber grommet - bulk pack - B850-18 - std qty 50
850R-1 Rectangular LED Rear Stop, Turn and Tail Light
Peterson Lighting Rectangular LED Rear Stop, Turn and Tail Light
For enhanced trucking safety, equip your truck with a high-quality Peterson Lighting rectangular LED rear stop, turn and tail light. This product effectively combines all three crucial functions—stop, turn, and tail— into one industry-standard light.
Features & Benefits
- An 11-diode rectangular LED light with stripped wires, superior optics, and 12" long leads
- With sealed lens and housing that meets IP67 ingress protection level
- Designed to fit 139mm x 91mm grommet hole with 19mm corner radii and surface-mount cluster pods (850-09)
- Comes with 2 meters (6 1/2 ft.) of sheathed cable and potted, hard-wired terminals for durability
- Product’s operating range is 9 to 32 volts and has a 100,000-hour rated life
- Designed to meet FMVSS 108 requirements in vertical or horizontal position
- Engineered to meet the needs of any stop tail turn lighting situation
PETERSON LIGHTING 850R-1 Specifications
Product Attributes
| Bulb Technology | LED |
| Bulb/diode Count | 11 |
| California Prop65 Required | Y |
| Container Type | poly bag |
| Height | 3.52 in |
| Integral Reflex | N |
| Length | 5.3 in |
| Lens Color | red |
| Light Color | red |
| Maximum Voltage | 32 Volts |
| Minimum Voltage | 9 Volts |
| Mounting Type | surface |
| Multi-volt | Y |
| Regulatory Compliance | DOT + ECE |
| Shape | rectangular |
| Submersible | Y |
| Termination | stripped wire |
| Voltage | 12V / 24V |
| Width | 1.34 in |
Additional Information
| Warranty Special | LIMITED LIFETIME WARRANTY See full warranty terms: https://pmlights.com/warranty |
| Warranty Special UOM | TX |
| Country of Origin (Primary) | TW |
| UPC | 00044464102498 |
| VMRS Code | 034002059 |
PETERSON LIGHTING 850R-1 Cross References
We have 2 alternatives for the 850R-1 by PETERSON LIGHTING:
PETERSON LIGHTING 850R-1 Manufacturer Information
Peterson Lighting® is a family-owned company that produces and distributes vehicle safety lighting systems mirrors, and other related safety products and accessories. It has been in the business for 75 years, and currently, it offers over 2,200 products designed for various applications, including tilt-bed and cargo vehicles and light- and medium-duty trailers. Peterson Lighting believes that full commitment to quality is its responsibility as a market leader. All its components are designed and manufactured only in its ISO 9001/QS-9000-certified facility in Grandview, MO. This facility is handled by knowledgeable and highly skilled specialists, who are as dedicated and passionate as the company when it comes to quality.
