RAYBESTOS 76323 Part Description
Manufacturer
Product Description
Raybestos Specialty - Street Performance Brake Rotor
Features & Benefits
- Application Specific Enhanced Iron
- Raybestos® Performance Rotors are made with enhanced iron which suppresses noise and keeps brakes running cool, quiet and vibration free.
- Raybestos(R) Performance Rotors are made with enhanced iron which suppresses noise and keeps brakes running cool, quiet and vibration free.
- Cooling Vanes
- The cooling vanes match OE configurations and provide optimal cooling and reduced fade.
- Application Specific Coating
- Depending on the application, Performance Rotors will have one of the following finishes: Black fusion coating on the rotor hat Grey Fusion 4.0® coating on the entire rotor
- Depending on the application, Performance Rotors will have one of the following finishes: Black fusion coating on the rotor hat Grey Fusion 4.0(R) coating on the entire rotor
- Black fusion coating on the rotor hat and Grey Fusion 4.0® coating on the rotor inboard surface and cooling vanes
- Black fusion coating on the rotor hat and Grey Fusion 4.0(R) coating on the rotor inboard surface and cooling vanes
- Turned Finish
- Turned finish minimizes noise and improves responsiveness for smoother stops.
- S-Groove Slot
- Depending on the application, some Raybestos® Performance Rotors are designed with a patented S-Groove Slot.
- Depending on the application, some Raybestos(R) Performance Rotors are designed with a patented S-Groove Slot.
Raybestos Specialty - Street Performance Brake Rotor
RAYBESTOS 76323 Specifications
Product Attributes
| ABS Tone Ring Included | No |
| Center Hole Diameter | 2.892 IN |
| Conventional Or Drum-In-Hat Type Rotor | Conventional |
| Discard Thickness | 0.882 IN |
| Mounting Bolt Hole Circle Diameter | 4.5 IN |
| Mounting Bolt Hole Diameter | 4.5 IN |
| Mounting Bolt Hole Quantity | 5 |
| Nominal Thickness | 0.945 IN |
| Outside Diameter | 11.1 IN |
| Overall Height | 2.055 IN |
| Solid Or Vented Type Rotor | Vented |
| Stud/Lug Hole Quantity | 5 |
| Harmonize Code | 8708.30.5030 |
| Salability Restrictions | No |
| UNSPSC Code | 25171715 |
| Center Hole Diameter | 73.45 MM |
| Discard Thickness | 22.4 MM |
| Mounting Bolt Hole Circle Diameter | 114.3 MM |
| Mounting Bolt Hole Diameter | 114.3 MM |
| Nominal Thickness | 24 MM |
| Outside Diameter | 281.95 MM |
| Overall Height | 52.2 MM |
Additional Information
| Country of Origin (Primary) | US |
| Canadian Harmonizing Tariff Code | 8708309990 |
| Harmonized Tariff Code (HTS) | 8708305030 |
| UPC | 00030999545169 |
RAYBESTOS 76323 Cross References
| Brand | Part Number |
|---|---|
| Advance Auto Parts | 141840, YH141840 |
| AutoZone | 5355, 5355B, DL5355 |
| Autopart International | 25551 |
| Autoxtra | 8076323, AX5355 |
| Bendix | 141840 |
| Bosch | RBR5355 |
| Brake Headquarters | BR53445 |
| Brake Pro | 4612120 |
| BrakeBest | 76323, 76323R, 76323RGS, 81-125309, BD125309 |
| Brembo | 09.8018.85, 27086 |
| Bridgestone | 7002428, 7095133 |
| CENTRIC | 120.63034, 121.63034 |
| California Drum & Rotor | 125309 |
| Casting Numbers | 210566-C, 211514-DP, 325168, 4644, 53551 |
| Centric Parts | 120.63034, 121.63034, 125.63034, 126.63034CSL, 126.63034CSR, 126.63034SL, 126.63034SR, 127.63034L, 127.63034R |
| Century | 7057 |
| Chrysler | 04582811 |
| Delphi | RB392 |
| Dura Corp | BR5355 |
| DuraGo | BR5355 |
| EIS Brakes | D17574 |
| Eagle | 4582811 |
| Eurorotor | 5355 |
| GREN | 601902 |
| Guardian | 52-125309 |
| MCI | 6071 |
| Midas | BR1890 |
| Mighty Distributing System | 5355 |
| Newtek Automotive USA | 5355 |
| PRONTO | BR5355 |
| Parts Master | P125309 |
| Pep Boys | 5355G |
| Promax | 14-5355 |
| Qualis | 5355, 5372 |
| Qualitee International | 64-91-730 |
| Quality Brand | 5355, Q4051 |
| Roadmates | 526167 |
| Standard Rotors and Drums | 5355 |
| TruStar | 491730, R91730 |
| UAP | 5355 |
| Ultra Brake | 5355 |
| Universal | 103550 |
| VIPAR - Vehicle Indusrty Parts & Manufacturing | X50687 |
| WAGNER | BD125309 |
| Wagner Brake | BD125309, SB76323 |
| Winhere | 442166, YH2166 |
