(888) 312-8812 Login SignupDELPHI TC4344 Control Arm and Ball Joint Assembly
Tap to view 27 more
$10899
Limited availability at this price!
In Stock
Get it by Monday, Dec 29
DELPHI TC4344 Part Description
Control Arm and Ball Joint Assembly
DELPHI TC4344 Specifications
Product Attributes
| Thread Direction | Clockwise (Right) |
| Bushing Color | Black |
| Finish | Painted |
| Pre-Greased | Yes |
| Bushings Included | Yes |
| Dust Boot Included | Yes |
| Ball Joint Mounting Type | Bolt In |
| Ball Joint Stud Type | Threaded |
| Ball Joint Included | Yes |
| Control Arm Construction | Stamped |
| Control Arm Material | Steel |
| Mounting Hardware Included | Yes |
| Grade Type | Premium |
| Mounting Hole Quantity | 2 |
| Boot Material | Chloroprene Rubber (CR) |
| Adjustable | Yes |
| Locking Nut Included | Yes |
| Greaseable | No |
| Control Arm Maximum Width | 447.00 MM |
| Control Arm Color | Black |
| Ball Joint Thread Diameter | 14.00 MM |
| Ball Joint Stud Length | 22.50 MM |
| Control Arm Maximum Length | 513.00 MM |
| Thread Diameter | 14.00 MM |
| Boot Color | Black |
| Steering Type | Power |
| Bearing Material | Plastic |
| Bushing Material | Rubber |
| Mounting Hole Diameter | 14.00 MM |
| Dust Boot Material | Chloroprene Rubber (CR) |
| Distance Between Bushings | 306.50 MM |
| Bushing Inside Diameter | 14.20 MM |
| Bushing Length | 60.00 MM |
| Position(s) | Front Right Lower |
| Control Arm Maximum Width | 17.598 IN |
| Ball Joint Thread Diameter | 0.551 IN |
| Ball Joint Stud Length | 0.886 IN |
| Control Arm Maximum Length | 20.197 IN |
| Thread Diameter | 0.551 IN |
| Mounting Hole Diameter | 0.551 IN |
| Distance Between Bushings | 12.067 IN |
| Bushing Inside Diameter | 0.559 IN |
| Bushing Length | 2.362 IN |
Additional Information
| Country of Origin (Primary) | TR |
| Harmonized Tariff Code (Schedule B) | 8708807000 |
| Harmonized Tariff Code (HTS) | 8708806590 |
| Warranty Special | Limited Lifetime |
| Warranty Special UOM | LF |
| UPC | 00689604393758 |
| VMRS Code | 016001001 |
| UNSPSC | 25172013 |
DELPHI TC4344 Part Interchanges
| Brand | Part Number |
|---|---|
| N/A | 102-8155, RK623649, CMS601240, 51350-TBA-A01 |
DELPHI TC4344 Fits Vehicles
- Honda Civic (2016-2021)
