WABCO 446 091 307 0 - Water Control Valve - 12 Volt, Tyco HDSCS, 3-pole
$21399
30 day lead time
. Learn more
WABCO part description
Water Control Valve - 12 Volt, Tyco HDSCS, 3-pole
Product Attributes
| Voltage | 12 V |
| Calculated Volume (dm³) | 0.6697 |
| Max. operating pressure | 2.5 bar |
| Variable Nominal Flow Rate | 5.80 L/min at p = 0.075 bar |
| Electrical connection | Tyco HDSCS, 3-pole |
| Medium | Anti-freeze water mixture G48, G12 (max. 1:1) |
| Size | 48 x 128 x 109 |
| Medium Temperature | -40°C to +125°C |
| Weight | 1.39 |
| Nominal flow rate | 5.830 (L/min) |
| Temperature Range | -40°C to +105°C |
Whether it’s for cars, buses, trucks, or trailers, WABCO® is at the frontline at developing and providing products and systems to make vehicles safer and easier to control. Founded in 1869, WABCO is a major supplier of braking, stability, suspension and transmissions in the Americas and beyond. The company is recognized as introducing the modern air brake system in 1869, and continues to lead the industry in air brake design and production for the heavy duty and commercial vehicle sectors. Today, WABCO operates as a division of the German auto parts maker ZF and employs 16,000 employees in facilities in 36 countries worldwide.
