(888) 312-8812 Login SignupWABCO 434 612 018 0 Air Brake Safety Valve - M22x1.5, 24 mm
Tap to view 3 more
$10899
14 Day Lead Time
Due to limited availability, we will confirm your order and notify you within 1 business day.
WABCO 434 612 018 0 Part Description
WABCO 434 612 018 0 Specifications
Product Attributes
| Opening Pressure | 12.0 bar |
| Size | 24 x 27 x 60 |
| Wrench Size | 24.0 mm |
| Nominal Diameter | 7.0 mm |
| Total Length | 72 mm |
| Weight | 0.26676 |
| Port threads | M22 x 1.5 |
| Temperature Range | -40°C to +80°C |
| Port thread 1 | M22 x 1.5 |
| Calculated Volume (dm³) | 0.03888 |
WABCO 434 612 018 0 Manufacturer Information
Whether it’s for cars, buses, trucks, or trailers, WABCO® is at the frontline at developing and providing products and systems to make vehicles safer and easier to control. Founded in 1869, WABCO is a major supplier of braking, stability, suspension and transmissions in the Americas and beyond. The company is recognized as introducing the modern air brake system in 1869, and continues to lead the industry in air brake design and production for the heavy duty and commercial vehicle sectors. Today, WABCO operates as a division of the German auto parts maker ZF and employs 16,000 employees in facilities in 36 countries worldwide.
