BILSTEIN 25-294071 Part Description
Manufacturer
Product Description
B8 8100 (DSA) - Suspension Shock Absorber
Application Summary
Toyota Tacoma 2023-2005
Features & Benefits
- 60mm large bore digressive piston offers a greater range of tunability and delivers exceptional comfort without sacrificing control
- Direct fit for an easy installation
- Click adjuster knobs allow easy and precise Dual Speed Adjustment of both low and high speed compression to tailor your ride to any surface
SUSPENSION SHOCK ABSORBER
BILSTEIN 25-294071 Specifications
Product Attributes
| Internal Design | Monotube |
| Adjustable Damping | Click Adjusters for High and Low Speed Compression |
| Finish | EVO Grey |
| Collapsed Length (mm) | 362.0 |
| Title | Bilstein Shock Absorbers |
| Lower Mount Type | Eye 12mm |
| Boot Included | No |
| Parttype | Shocks / Struts |
| Body Design | Smooth Body (Non-Coilover) |
| RESERVOIR | Yes |
| Prop 65 (Y/N) | Y |
| Series | B8 8100 (DSA) |
| Extended Length (in) | 22.80 |
| Upper Mount Type | Stem |
| Collapsed Length (in) | 14.25 |
| Extended Length (mm) | 579.0 |
| Segment | Light Truck |
| Body Diameter (id) | 60mm |
| Spring Seat Included | No |
| Piston Diameter | 60mm |
| Shaft Diameter | 18mm |
Additional Information
| MSDS Sheet Number | USA SDS_Shock_Air Spring_V2_EN.pdf |
| Remanufactured Part | N |
| Refurbished Part | N |
| Warranty Time | 24 |
| Warranty Time UOM | MO |
| Country of Origin (Primary) | US |
| Harmonized Tariff Code (Schedule B) | 8708800050 |
| Harmonized Tariff Code (HTS) | 8708801600 |
| UPC | 00651860908168 |
BILSTEIN 25-294071 Cross References
| Brand | Part Number |
|---|---|
| FOX Offroad Shocks | 57805CP |
| ICON Vehicle Dynamics | 57805CP |
| King Shocks | 25001-121A |
| Old Man Emu | BP5160011L, BP5160011R |
BILSTEIN 25-294071 Fits Vehicles
- Toyota Tacoma (2005-2023)
