(888) 312-8812 Login SignupMERITOR A3211J5782 Air Brake Spider, 7.25 in. Bolt Circle Diameter, 5.50 in. Pilot Diameter
$31849
3 Day Lead Time
Due to limited availability, we will confirm your order and notify you within 1 business day.
MERITOR A3211J5782 Part Description
Manufacturer
Product Description
Air Brake, Spider Assembly
Features & Benefits
- Mechanical brake layout stays organized around the spider body
- Bolt circle detail sets the mounting pattern for the brake spider
- Pilot diameter helps locate the assembly at the axle-end position
- Foundation structure carries shoe, anchor, and cam hardware together
Meritor Air Brake Spider
The Meritor Air Brake Spider forms the foundation mounting structure for drum brake hardware at the axle end. This spider assembly uses a 7.25-inch bolt circle and 5.50-inch pilot diameter, giving the brake setup defined mounting details for proper placement. It holds the anchor, cam, shoe, and related mechanical brake areas in position as air brake force moves into the foundation assembly. The spider’s role stays structural, while air pressure control happens through separate valves, chambers, and lines. The Meritor A3211J5782 places the brake hardware around a measured axle-end mounting base.
| VMRS Code | 013-002-105 |
MERITOR A3211J5782 Specifications
Product Attributes
| Bolt Circle Diameter | 7.25 in. |
| Brand | Meritor |
| Pallet Quantity | 48 |
| Pilot Diameter | 5.50 in. |
| Weight | 14.35 |
MERITOR A3211J5782 Cross References
| Brand | Part Number |
|---|---|
| TDAA3211J5782, KM5172, 2503564C91, 8235A3211J5782, 88936261, A3211J5782RI, ATIA3211J5782 |
MERITOR A3211J5782 Customer Reviews
No reviews yet
Be the first to review this product!
MERITOR A3211J5782 Manufacturer Information
Meritor®, whose roots could be traced back to 1909, is backed by over 100 years of industry experience plus a massive portfolio of products for various industries. In 1998, it made several acquisitions, including Volvo Trucks' heavy vehicle manufacturing operation in Sweden, Euclid Industries, and Lucas Varity's Heavy Vehicle Braking Systems division. Such investments solidify Meritor's position as the leading global supplier of brakes, axles, drivelines, transmissions, suspensions, tire inflations systems, and a whole lot of parts, hardware, and accessories for the automotive, truck, trailer, rail cars, bus and coach, and many other applications. Its "Run with the Bull" global brand identity further strengthens its commitment to provide the industry with durable products, unparalleled service and support, and continuous innovation.
