(888) 312-8812 Login SignupRAYBESTOS 8529 Raybestos Specialty - Truck Brake Rotor
$414.32
MSRP Pricing shown.
Out of Stock
We cannot fulfill orders for this part at this time. Please check back later or request a stock notification to receive an email.
We may have similar parts for sale. Search Alternatives >
RAYBESTOS 8529 Part Description
Manufacturer
Product Description
Raybestos Specialty - Truck Brake Rotor
Application Summary
1997-1990 International 4900 Front, 1997-1990 International 3800 Front, 1997-1990 International 4700 Front, 1994-1990 International 3700 Front, 1997-1992 International 3600 Front, 1995-1990 International 4600 Front
Features & Benefits
- OE Fit, Form, and Function
- Our vehicle-specific design matches OE fit, form and function, providing ultimate strength and performance
- Cooling Vanes
- We dedicate time to match the cooling vanes on our Specialty rotors to OE designs, ensuring: Optimal cooling Reduced fade Less noise Increased pad life
- Coating
- All Specialty rotors are protected against the elements. All new Specialty rotors come fully coated with Grey Fusion 4.0® rated at 300 hrs. salt spray or a Black Fusion painted hat and edge for rust protection.
- All Specialty rotors are protected against the elements. All new Specialty rotors come fully coated with Grey Fusion 4.0(R) rated at 300 hrs. salt spray or a Black Fusion painted hat and edge for rust protection.
- SAE Standard for Tensile Strength
- Our rotors follow SAE standards for tensile strength, hardness, and iron grade, providing structural integrity and maximum service life
- Turned Finish
- A turned finish provides an excellent surface for the pads to engage with to ensure a smooth and effective stop right out of the box
RAYBESTOS 8529 Specifications
Product Attributes
| ABS Tone Ring Included | No |
| Center Hole Diameter | 9.375 IN |
| Center Hole Diameter | 238.15 MM |
| Conventional Or Drum-In-Hat Type Rotor | Conventional |
| Discard Thickness | 1.32 IN |
| Discard Thickness | 33.55 MM |
| Harmonize Code | 8708.30.5030 |
| Mounting Bolt Hole Circle Diameter | 11.25 IN |
| Mounting Bolt Hole Circle Diameter | 285.75 MM |
| Mounting Bolt Hole Diameter | 0.807 IN |
| Mounting Bolt Hole Diameter | 20.5 MM |
| Mounting Bolt Hole Quantity | 10 |
| Nominal Thickness | 1.435 IN |
| Nominal Thickness | 36.45 MM |
| Outside Diameter | 15 IN |
| Outside Diameter | 381 MM |
| Overall Height | 6.8 IN |
| Overall Height | 172.7 MM |
| Salability Restrictions | No |
| Solid Or Vented Type Rotor | Vented |
| Stud/Lug Hole Quantity | 10 |
| UNSPSC Code | 25171715 |
Additional Information
| Country of Origin (Primary) | US |
| Canadian Harmonizing Tariff Code | 8708309990 |
| Harmonized Tariff Code (HTS) | 8708305030 |
| UPC | 00030999966193 |
RAYBESTOS 8529 Cross References
| Brand | Part Number |
|---|---|
| 29545638, 30999966193 | |
| ADVANCE AUTO PARTS | YH141608, YH141608C, YH141608P |
| AMERICAN REMANUFACTURED | 89-54007 |
| AUTOSPECIALTY | AR9307 |
| BENDIX | 141608 |
| BRAKEBEST | 8529, 8529RGS |
| CENTRIC | 120.83007, 121.83007 |
| Centric Parts | 120.83007, 121.83007 |
| DAYTON WALTHER | 23122945 |
| DURA CORP | BR5611 |
| EUCLID | E-4243 |
| FORMULA BLUE HYDRAULIC BRAKE PARTS | E12588012 |
| GUNITE | D6145, R6145 |
| INTERNATIONAL HARVESTER (IHC) | 582029C1 |
| MIGHTY DISTRIBUTING SYSTEM | 5611 |
| Qualis | 5611 |
| UAP | 5611 |
| WAGNER | BD126394 |
| WAGNER BRAKE | BD126394 |
RAYBESTOS 8529 Fits Vehicles
- International 1854 (1983-1989)
- International 1824 (1983-1984)
- International 1955 (1979-1982)
- International 1954 (1979-1982)
- International 1925 S (1979-1982)
- International 1924 S (1979-1982)
- International F1954 (1986-1989)
- International S1955 (1981-1989)
- International S1954 (1981-1989)
- International S1925 (1980-1982)
- International S1924 (1980-1982)
- International S1854 (1983-1989)
- International S1853FC (1987-1989)
- International S1853 (1983-1989)
- International S1824 (1983-1985)
- International 4600UH (1990)
- International Genesis RE (1996-1997)
- International 3000RE (1996-1997)
- International 3000 (1996-1997)
- International 2674 (1990-1998)
- International 7100 (1990-1995)
- International 4900 (1990-1997)
- International 4800 (1990-1997)
- International 4700LPX (1995-1997)
- International 4700LP (1990-1997)
- International 4700 (1990-1997)
- International 4600LP (1990-1994)
- International 4600 (1990-1995)
- International 3900FC (1991-1994, 1996)
- International 3800 (1990-1997)
- International 3700 (1990-1994)
- International 3600 (1992-1997)
- International 3400 (1996-1997)
- International 3000FE (1997)
- International 2574 (1994-1998)
- International 2654 (1990-1998)
- International 2554 (1990-1998)
- International M1600 Metro II (1987-1990)
- International M1400 Metro II (1987-1990)
- International 1652SC (1986-1993)
- International 1452SC (1987-1992)
- Blue Bird TC1000 (1997-2000)
- Blue Bird SHL TC2000 (1993-2003)
- Blue Bird TC2000 (1989-2004)
