RAYBESTOS 680180 Part Description
Manufacturer
Product Description
Raybestos Specialty - Truck Brake Rotor
Application Summary
2008-2004 Ford F-150 Front, 2008-2006 Lincoln Mark LT Front, 2008-2004 Ford Lobo Front
Features & Benefits
- OE Fit, Form, and Function
- Our vehicle-specific design matches OE fit, form and function, providing ultimate strength and performance
- Cooling Vanes
- We dedicate time to match the cooling vanes on our Specialty rotors to OE designs, ensuring: Optimal cooling Reduced fade Less noise Increased pad life
- Coating
- All Specialty rotors are protected against the elements. All new Specialty rotors come fully coated with Grey Fusion 4.0® rated at 300 hrs. salt spray or a Black Fusion painted hat and edge for rust protection.
- All Specialty rotors are protected against the elements. All new Specialty rotors come fully coated with Grey Fusion 4.0(R) rated at 300 hrs. salt spray or a Black Fusion painted hat and edge for rust protection.
- SAE Standard for Tensile Strength
- Our rotors follow SAE standards for tensile strength, hardness, and iron grade, providing structural integrity and maximum service life
- Turned Finish
- A turned finish provides an excellent surface for the pads to engage with to ensure a smooth and effective stop right out of the box
RAYBESTOS 680180 Specifications
Product Attributes
| ABS Tone Ring Included | No |
| Center Hole Diameter | 3.55 IN |
| Center Hole Diameter | 90.15 MM |
| Conventional Or Drum-In-Hat Type Rotor | Conventional |
| Directional or Non-Directional Brake Surface | Non-Directional |
| Discard Thickness | 1.122 IN |
| Discard Thickness | 28.5 MM |
| Harmonize Code | 8708.30.5030 |
| Material | Cast Iron |
| Mounting Bolt Hole Circle Diameter | 5.315 IN |
| Mounting Bolt Hole Circle Diameter | 135 MM |
| Mounting Bolt Hole Diameter | 0.604 IN |
| Mounting Bolt Hole Diameter | 15.35 MM |
| Mounting Bolt Hole Quantity | 6 |
| Nominal Thickness | 1.18 IN |
| Nominal Thickness | 29.95 MM |
| Outside Diameter | 12.99 IN |
| Outside Diameter | 329.95 MM |
| Overall Height | 2.13 IN |
| Overall Height | 54.1 MM |
| Salability Restrictions | No |
| Solid Or Vented Type Rotor | Vented |
| Stud/Lug Hole Quantity | 6 |
| UNSPSC Code | 25171715 |
Additional Information
| Country of Origin (Primary) | CN |
| Canadian Harmonizing Tariff Code | 8708309990 |
| Harmonized Tariff Code (HTS) | 8708305030 |
| UPC | 00747730872186 |
RAYBESTOS 680180 Cross References
| Brand | Part Number |
|---|---|
| 77416711, 747730872186 | |
| ADVANCE AUTO PARTS | 145527, N1000192486APO, YH145527, YH145527C, YH145527P |
| AUTOPARTSOURCE | 592525 |
| AUTOXTRA | 80680180, AX54109 |
| AUTOZONE | 54109, 54109DG |
| Autoxtra | AX54109P |
| BENDIX | 145527 |
| BRAKEBEST | 680180, 680180FZN, 680180PER, 680180R, 680180RGS, 81-126111, BD126111 |
| BREMBO | 09.B597.10, 27363 |
| Brembo | 09.B597.11 |
| CENTRIC | 120.65100, 120.65100CRY, 121.65100, 125.65100, 125.65100CRY, 126.65100CSL, 126.65100CSR, 126.65100SL, 126.65100SR, 127.65100CL, 127.65100CR, 127.65100L, 127.65100R, 128.65100CL, 128.65100CR, 128.65100L, 128.65100R, 227.65100L, 227.65100R, 320.65100, 320.65100F, 321.65100, 120.651 |
| Casting Numbers | 325625 |
| Centric Parts | 120.65100, 120.65100CRY, 121.65100, 125.65100, 125.65100CRY, 126.65100CSL, 126.65100CSR, 126.65100SL, 126.65100SR, 127.65100CL, 127.65100CR, 127.65100L, 127.65100R, 128.65100CL, 128.65100CR, 128.65100L, 128.65100R, 227.65100L, 227.65100R, 320.65100, 320.65100F, 321.65100 |
| DURA CORP | BR54109, BR5410902 |
| DuraGo | BR54109, BR5410902, BR54109-02 |
| EUCLID | E-14552A |
| Eurorotor | 54293 |
| FORD | 4L3Z1125AA, 4U2Z1V125CA, 4U2Z1V125CB, 5L3Z1125AA |
| GREN | 629702 |
| MAGMA PRODUCTS | PSR205214 |
| MIGHTY DISTRIBUTING SYSTEM | 54109 |
| MONROE BRAKES | BD126111 |
| MOTORCRAFT | BRR120, BRR230 |
| Motorcraft | NBRR5 |
| NEOTEK | 1071025GF |
| NEWTEK AUTOMOTIVE | 54109 |
| Newtek Automotive USA | 54109 |
| POWERSTOP | AR8596EVC |
| PROMAX | 14-54109, 20-54109 |
| PRONTO | BR54109 |
| Parts Master | 126111 |
| QUALIS | 42126, 54109 |
| QUALITY BRAND | Q4190 |
| STANDARD ROTORS AND DRUMS | 54109 |
| TopNotch | TN680180GEO |
| UAP | 54109 |
| Ultra Brake | 54293 |
| VIPAR - VEHICLE INDUSRTY PARTS & MANUFACTURING | X51548 |
| WABCO | PS126111 |
| WABCO - Archived | PS126111 |
| WAGNER | BD126111, BD126111E |
| WAGNER BRAKE | BD126111, BD126111E |
| WINHERE | 6620231 |
| WORLDPAC | 1407-26843, 1427-499316 |
RAYBESTOS 680180 Fits Vehicles
- Ford F-150 Heritage (2004)
- Ford Lobo (2004-2008)
- Lincoln Mark LT (2006-2008)
- Ford F-150 (2004-2008)
