RAYBESTOS 980396 Part Description
Manufacturer
Product Description
Raybestos Specialty - Street Performance Brake Rotor
Application Summary
2007-2004 BMW 530i Front, 2010-2008 BMW 528i Front, 2007-2004 BMW 525i Front, 2007-2006 BMW 530xi Front, 2010-2009 BMW 528i xDrive Front, 2008 BMW 535xi Front, 2010-2009 BMW 535i xDrive Front, 2008 BMW 528xi Front
Features & Benefits
- Application Specific Enhanced Iron
- Raybestos® Performance Rotors are made with enhanced iron which suppresses noise and keeps brakes running cool, quiet and vibration free.
- Raybestos(R) Performance Rotors are made with enhanced iron which suppresses noise and keeps brakes running cool, quiet and vibration free.
- Cooling Vanes
- The cooling vanes match OE configurations and provide optimal cooling and reduced fade.
- Application Specific Coating
- Depending on the application, Performance Rotors will have one of the following finishes: Black fusion coating on the rotor hat Grey Fusion 4.0® coating on the entire rotor
- Depending on the application, Performance Rotors will have one of the following finishes: Black fusion coating on the rotor hat Grey Fusion 4.0(R) coating on the entire rotor
- Black fusion coating on the rotor hat and Grey Fusion 4.0® coating on the rotor inboard surface and cooling vanes
- Black fusion coating on the rotor hat and Grey Fusion 4.0(R) coating on the rotor inboard surface and cooling vanes
- Turned Finish
- Turned finish minimizes noise and improves responsiveness for smoother stops.
- S-Groove Slot
- Depending on the application, some Raybestos® Performance Rotors are designed with a patented S-Groove Slot.
- Depending on the application, some Raybestos(R) Performance Rotors are designed with a patented S-Groove Slot.
RAYBESTOS 980396 Specifications
Product Attributes
| ABS Tone Ring Included | No |
| Center Hole Diameter | 3.11 IN |
| Center Hole Diameter | 79 MM |
| Conventional Or Drum-In-Hat Type Rotor | Conventional |
| Discard Thickness | 1.118 IN |
| Discard Thickness | 28.4 MM |
| Harmonize Code | 8708.30.5030 |
| Mounting Bolt Hole Circle Diameter | 4.724 IN |
| Mounting Bolt Hole Circle Diameter | 120 MM |
| Mounting Bolt Hole Diameter | 0.575 IN |
| Mounting Bolt Hole Diameter | 14.6 MM |
| Mounting Bolt Hole Quantity | 5 |
| Nominal Thickness | 1.181 IN |
| Nominal Thickness | 30 MM |
| Outside Diameter | 12.746 IN |
| Outside Diameter | 323.75 MM |
| Overall Height | 3.032 IN |
| Overall Height | 77 MM |
| Salability Restrictions | No |
| Solid Or Vented Type Rotor | Vented |
| Stud/Lug Hole Quantity | 5 |
| Surface Type | Smooth |
| UNSPSC Code | 25171715 |
Additional Information
| Country of Origin (Primary) | DE |
| Canadian Harmonizing Tariff Code | 8708309990 |
| Harmonized Tariff Code (HTS) | 8708305030 |
| UPC | 00829352360200 |
RAYBESTOS 980396 Cross References
| Brand | Part Number |
|---|---|
| 829352360200, 120.34070 | |
| ADVANCE AUTO PARTS | N1000149941ZIC, YH200356, YH200356C, YH200356P |
| ATE BRAKE PRODUCTS | SP30173, 430173 |
| AUTOXTRA | AX900730 |
| AUTOZONE | 34283, 34283DG |
| BENDIX | PRT6080 |
| BMW | 34116753221 |
| BOSCH | 15010118 |
| BRAKEBEST | 15010118, 980396, 980396FZN, 980396R, 980396RGS |
| BREMBO | 25744 |
| CENTRIC | 120.34070, 121.34070, 125.34070, 125.34070CRY, 126.34070CSL, 126.34070CSR, 126.34070SL, 126.34070SR, 127.34070L, 127.34070R, 128.34070CL, 128.34070CR, 128.34070L, 128.34070R, 227.34070L, 227.34070R, 320.34070, 320.34070H |
| Centric Parts | 120.34070, 121.34070, 125.34070, 125.34070CRY, 126.34070CSL, 126.34070CSR, 126.34070SL, 126.34070SR, 127.34070L, 127.34070R, 128.34070CL, 128.34070CR, 128.34070L, 128.34070R, 227.34070L, 227.34070R, 320.34070, 320.34070H |
| DURA CORP | BR34283, BR900730, BR90073002 |
| DuraGo | 900730, BR900730, BR90073002 |
| MAGMA PRODUCTS | PSR123066 |
| NAPA BRAKES | SDK6450 |
| NEOTEK | 106681GF |
| NEWTEK AUTOMOTIVE | 34283 |
| Newtek Automotive USA | 34283 |
| PAGID | 355109922 |
| PAGID Racing | 355109922 |
| PILENGA | V818 |
| POWERSTOP | EBR1022EVC, EBR870EVC, EBR874EVC |
| PROMAX | 14-34283 |
| PRONTO | BR900730 |
| QUALIS | 45467 |
| Qualis | 45474 |
| STANDARD ROTORS AND DRUMS | GP34283 |
| TRW | 4361 |
| UAP | 34283 |
| VAICO | V2080051 |
| VIPAR - VEHICLE INDUSRTY PARTS & MANUFACTURING | X51738 |
| WABCO | PS34283 |
| WABCO - Archived | PS34283 |
| WAGNER | BD126521E, BD126113 |
| WAGNER BRAKE | BD126521 |
| WINHERE | 6620344 |
| WORLDPAC | 1407-75768, 1427-731831 |
| Wagner Brake | BD126521E |
| Zimmermann | 150.3403.20 |
RAYBESTOS 980396 Fits Vehicles
- BMW 535i xDrive (2009-2010)
- BMW 528i xDrive (2009-2010)
- BMW 535xi (2008)
- BMW 528xi (2008)
- BMW 528i (2008-2010)
- BMW 530xi (2006-2007)
- BMW 525xi (2006-2007)
- BMW 525i (2004-2007)
- BMW 530i (2004-2007)
