RAYBESTOS 980587 Raybestos Specialty - Truck Brake Rotor

(0)

$158.99

Limited availability at this price!

In Stock

Get it by Wednesday, Aug 12
No Hassle Return Policy Details
Free Ground shipping on orders over $499 details

RAYBESTOS 980587 Part Description

Manufacturer

RAYBESTOS

Product Description

Raybestos Specialty - Truck Brake Rotor

Application Summary

2004-1996 Mitsubishi Fuso FE-SP Rear, 2009-2005 Mitsubishi Fuso FE145 Rear, 2007-2006 Mitsubishi Fuso FE140 Rear, 2004-1996 Mitsubishi Fuso FE Rear, 2004-1996 Mitsubishi Fuso FE-HD Rear, 2009-2007 Sterling Truck 360 Rear

Features & Benefits

  • OE Fit, Form, and Function
  • Our vehicle-specific design matches OE fit, form and function, providing ultimate strength and performance
  • Cooling Vanes
  • We dedicate time to match the cooling vanes on our Specialty rotors to OE designs, ensuring: Optimal cooling Reduced fade Less noise Increased pad life
  • Coating
  • All Specialty rotors are protected against the elements. All new Specialty rotors come fully coated with Grey Fusion 4.0® rated at 300 hrs. salt spray or a Black Fusion painted hat and edge for rust protection.
  • All Specialty rotors are protected against the elements. All new Specialty rotors come fully coated with Grey Fusion 4.0(R) rated at 300 hrs. salt spray or a Black Fusion painted hat and edge for rust protection.
  • SAE Standard for Tensile Strength
  • Our rotors follow SAE standards for tensile strength, hardness, and iron grade, providing structural integrity and maximum service life
  • Turned Finish
  • A turned finish provides an excellent surface for the pads to engage with to ensure a smooth and effective stop right out of the box

RAYBESTOS 980587 Specifications

Product Attributes

ABS Tone Ring Included No
Center Hole Diameter 4.882 IN
Center Hole Diameter 124 MM
Conventional Or Drum-In-Hat Type Rotor Conventional
Discard Thickness 1.476 IN
Discard Thickness 37.5 MM
Harmonize Code 8708.30.5030
Inside Diameter 6.772 IN
Inside Diameter 172 MM
Mounting Bolt Hole Circle Diameter 5.669 IN
Mounting Bolt Hole Circle Diameter 144 MM
Mounting Bolt Hole Diameter 0.396 IN
Mounting Bolt Hole Diameter 10.05 MM
Mounting Bolt Hole Quantity 12
Nominal Thickness 1.575 IN
Nominal Thickness 40 MM
Outside Diameter 11.535 IN
Outside Diameter 293 MM
Overall Height 2.748 IN
Overall Height 69.8 MM
Salability Restrictions No
Solid Or Vented Type Rotor Vented
Stud/Lug Hole Quantity 12
UNSPSC Code 25171715

Additional Information

Country of Origin (Primary) CN
Canadian Harmonizing Tariff Code 8708309990
Harmonized Tariff Code (HTS) 8708305030
UPC 00829352623879

RAYBESTOS 980587 Cross References

BrandPart Number
BRPK5554, 829352623879
Advance Auto PartsYH528124P
BRAKEBEST980587, 980587R, 980587RGS
CENTRIC120.46059, 121.46059
Casting Numbers326421
Centric Parts120.46059, 121.46059
DURA CORPBR31485, BR901554
DuraGoBR901554
Dynamic Friction Company604-60003
MAGMA PRODUCTSPSR407037
MITSUBISHIMC894848
NEWTEK AUTOMOTIVE31485
Newtek Automotive USA31485
Qualis44776

RAYBESTOS 980587 Fits Vehicles

  • Mitsubishi Fuso Canter FE125 (2012-2014)
  • Mitsubishi Fuso FE125 (2008)
  • Sterling Truck 360 (2007-2009)
  • Mitsubishi Fuso FE140 (2006-2007)
  • Mitsubishi Fuso FE145 (2005-2011)
  • Mitsubishi Fuso FE145CC (2005-2011)
  • Mitsubishi Fuso FE120 (2005)
  • Mitsubishi Fuso FE-CA (2001)
  • Mitsubishi Fuso FE-SP (1996-2004)
  • Mitsubishi Fuso FE-HD (1996-2004)
  • Mitsubishi Fuso FE (1996-2004)
