(888) 312-8812 Login SignupRAYBESTOS 580064 Raybestos Specialty - Street Performance Brake Rotor
$13499
Limited availability at this price!
1 Day Lead Time
Get it by Friday, Sep 4
RAYBESTOS 580064 Part Description
Manufacturer
Product Description
Raybestos Specialty - Street Performance Brake Rotor
Application Summary
2004 Pontiac GTO Front
Features & Benefits
- Application Specific Enhanced Iron
- Raybestos® Performance Rotors are made with enhanced iron which suppresses noise and keeps brakes running cool, quiet and vibration free.
- Raybestos(R) Performance Rotors are made with enhanced iron which suppresses noise and keeps brakes running cool, quiet and vibration free.
- Cooling Vanes
- The cooling vanes match OE configurations and provide optimal cooling and reduced fade.
- Application Specific Coating
- Depending on the application, Performance Rotors will have one of the following finishes: Black fusion coating on the rotor hat Grey Fusion 4.0® coating on the entire rotor
- Depending on the application, Performance Rotors will have one of the following finishes: Black fusion coating on the rotor hat Grey Fusion 4.0(R) coating on the entire rotor
- Black fusion coating on the rotor hat and Grey Fusion 4.0® coating on the rotor inboard surface and cooling vanes
- Black fusion coating on the rotor hat and Grey Fusion 4.0(R) coating on the rotor inboard surface and cooling vanes
- Turned Finish
- Turned finish minimizes noise and improves responsiveness for smoother stops.
- S-Groove Slot
- Depending on the application, some Raybestos® Performance Rotors are designed with a patented S-Groove Slot.
- Depending on the application, some Raybestos(R) Performance Rotors are designed with a patented S-Groove Slot.
RAYBESTOS 580064 Specifications
Product Attributes
| ABS Tone Ring Included | No |
| Center Hole Diameter | 2.818 IN |
| Center Hole Diameter | 71.6 MM |
| Conventional Or Drum-In-Hat Type Rotor | Conventional |
| Discard Thickness | 0.984 IN |
| Discard Thickness | 25 MM |
| Harmonize Code | 8708.30.5030 |
| Mounting Bolt Hole Circle Diameter | 4.724 IN |
| Mounting Bolt Hole Circle Diameter | 120 MM |
| Mounting Bolt Hole Diameter | 0.508 IN |
| Mounting Bolt Hole Diameter | 12.9 MM |
| Mounting Bolt Hole Quantity | 5 |
| Nominal Thickness | 1.105 IN |
| Nominal Thickness | 28.05 MM |
| Outside Diameter | 11.64 IN |
| Outside Diameter | 295.65 MM |
| Overall Height | 3.23 IN |
| Overall Height | 82.05 MM |
| Salability Restrictions | No |
| Solid Or Vented Type Rotor | Solid |
| Stud/Lug Hole Quantity | 5 |
| UNSPSC Code | 25171715 |
Additional Information
| Country of Origin (Primary) | CN |
| Canadian Harmonizing Tariff Code | 8708309990 |
| Harmonized Tariff Code (HTS) | 8708305030 |
| UPC | 00747730936857 |
RAYBESTOS 580064 Cross References
| Brand | Part Number |
|---|---|
| ACDELCO | 177-0957 |
| ADVANCE AUTO PARTS | YH145410 |
| AUTOSPECIALTY | AR8278 |
| AUTOZONE | 55088 |
| BENDIX | 145410 |
| BOSCH | 25010690 |
| BRAKEBEST | 25010690, 580064, 580064R, 580064RGS, BD126204 |
| BREMBO | 27335 |
| BrakeBest | 580065RGS |
| CENTRIC | 120.62081, 120.62081CRY, 121.62081, 126.62081SR, 126.62081CSL, 126.62081CSR, 126.62081SL, 128.62081L |
| Casting Numbers | 211455-C, 325972 |
| Centric Parts | 120.62081, 120.62081CRY, 121.62081, 126.62081CSL, 126.62081CSR, 126.62081SL, 126.62081SR, 128.62081L |
| DURA CORP | BR55088 |
| DuraGo | BR55088 |
| Dynamic Friction Company | 604-52015 |
| GM | 92228515, 92057139, 92155976 |
| General Motors | 92057139, 92155976, 92228515 |
| MIGHTY DISTRIBUTING SYSTEM | 55088 |
| NEWTEK AUTOMOTIVE | 55088 |
| Newtek Automotive USA | 55088 |
| PROMAX | 14-55088 |
| PRONTO | BR55088 |
| QUALIS | 55088 |
| QUALITEE INTERNATIONAL | 64-93-485 |
| TRUSTAR | 493485, R93485 |
| UAP | 55088 |
| VIPAR - VEHICLE INDUSRTY PARTS & MANUFACTURING | X51662 |
| WAGNER | BD126204 |
| WAGNER BRAKE | BD126204 |
| WINHERE | 442910 |
RAYBESTOS 580064 Fits Vehicles
- Pontiac GTO (2004)
