(888) 312-8812 Login SignupRAYBESTOS 76918 Raybestos Specialty - Truck Brake Rotor
$19299
Limited availability at this price!
In Stock
Get as soon as Wednesday, Oct 7
RAYBESTOS 76918 Part Description
Manufacturer
Product Description
Raybestos Specialty - Truck Brake Rotor
Application Summary
2001-2000 Dodge Ram 1500 Front
Features & Benefits
- OE Fit, Form, and Function
- Our vehicle-specific design matches OE fit, form and function, providing ultimate strength and performance
- Cooling Vanes
- We dedicate time to match the cooling vanes on our Specialty rotors to OE designs, ensuring: Optimal cooling Reduced fade Less noise Increased pad life
- We dedicate time to match the cooling vanes on our Specialty rotors to OE designs, ensuring:Optimal coolingReduced fadeLess noiseIncreased pad life
- Coating
- All Specialty rotors are protected against the elements. All new Specialty rotors come fully coated with Grey Fusion 4.0® rated at 300 hrs. salt spray or a Black Fusion painted hat and edge for rust protection.
- All Specialty rotors are protected against the elements. All new Specialty rotors come fully coated with Grey Fusion 4.0(R) rated at 300 hrs. salt spray or a Black Fusion painted hat and edge for rust protection.
- SAE Standard for Tensile Strength
- Our rotors follow SAE standards for tensile strength, hardness, and iron grade, providing structural integrity and maximum service life
- Turned Finish
- A turned finish provides an excellent surface for the pads to engage with to ensure a smooth and effective stop right out of the box
RAYBESTOS 76918 Specifications
Product Attributes
| ABS Tone Ring Included | No |
| Center Hole Diameter | 3.14 IN |
| Center Hole Diameter | 79.75 MM |
| Conventional Or Drum-In-Hat Type Rotor | Conventional |
| Directional or Non-Directional Brake Surface | Non-Directional |
| Discard Thickness | 1.118 IN |
| Discard Thickness | 28.4 MM |
| Harmonize Code | 8708.30.5030 |
| Material | Cast Iron |
| Mounting Bolt Hole Circle Diameter | 5.5 IN |
| Mounting Bolt Hole Circle Diameter | 139.7 MM |
| Mounting Bolt Hole Diameter | 0.625 IN |
| Mounting Bolt Hole Diameter | 15.9 MM |
| Mounting Bolt Hole Quantity | 5 |
| Nominal Thickness | 1.18 IN |
| Nominal Thickness | 29.95 MM |
| Outside Diameter | 11.97 IN |
| Outside Diameter | 304.05 MM |
| Overall Height | 2.74 IN |
| Overall Height | 69.6 MM |
| Salability Restrictions | No |
| Solid Or Vented Type Rotor | Vented |
| Stud/Lug Hole Quantity | 5 |
| UNSPSC Code | 25171715 |
Additional Information
| Country of Origin (Primary) | CN |
| Canadian Harmonizing Tariff Code | 8708309990 |
| Harmonized Tariff Code (HTS) | 8708305030 |
| UPC | 00747730627090 |
RAYBESTOS 76918 Cross References
| Brand | Part Number |
|---|---|
| 74820243, 747730627090 | |
| ADVANCE AUTO PARTS | 145306, YH145306, YH145306C, YH145306P |
| AMERICAN REMANUFACTURED | 89-40048 |
| AUTOSPECIALTY | AR8747, AR8747E |
| AUTOZONE | 5395DG, 5395, DL5395 |
| BENDIX | 145306 |
| BOSCH | 16010175, RBR5395 |
| BRAKEBEST | 16010175, 76918, 76918R, 76918RGS, 81-125751, BD125751 |
| BREMBO | 09.8919.85, 27228, 09.8919.21 |
| CENTRIC | 120.67048, 121.67048, 125.67048, 126.67048CSL, 126.67048CSR, 126.67048SL, 126.67048SR, 127.67048L, 127.67048R, 227.67048L, 227.67048R, 320.67048, 320.67048F |
| CHRYSLER | 52009865AA |
| CONTINENTAL-CONTITECH | CW30713 |
| Casting Numbers | 211275-C, 2539729, 325515 |
| Centric Parts | 120.67048, 121.67048, 125.67048, 126.67048CSL, 126.67048CSR, 126.67048SL, 126.67048SR, 127.67048L, 127.67048R, 227.67048L, 227.67048R, 320.67048, 320.67048F |
| DURA CORP | BR5395 |
| DuraGo | BR5395 |
| GUARDIAN | 52-125751 |
| MAGMA PRODUCTS | PSR145150 |
| MIDAS | BR2191 |
| MIGHTY DISTRIBUTING SYSTEM | 5395 |
| NEOTEK | 107033GF |
| NEWTEK AUTOMOTIVE | 5395 |
| Newtek Automotive USA | 5395 |
| POWERSTOP | AR8747EVC |
| PROMAX | 14-5395 |
| PRONTO | BR5395 |
| QUALIS | 5395 |
| QUALITY BRAND | 5395 |
| STANDARD ROTORS AND DRUMS | 5395 |
| THE UNIVERSAL GROUP | 103166 |
| UAP | 5395 |
| Ultra Brake | 5395 |
| Universal | 103166 |
| VIPAR - VEHICLE INDUSRTY PARTS & MANUFACTURING | X51343 |
| WABCO | PS125751 |
| WABCO - Archived | PS125751 |
| WAGNER | BD125751 |
| WAGNER BRAKE | BD125751 |
| WINHERE | 442598, YH2598 |
| WORLDPAC | 1407-24993 |
| Wagner Brake | BD125751E |
RAYBESTOS 76918 Fits Vehicles
- Dodge Ram 1500 (2000-2001)
- Dodge Ramcharger (2000-2001)
