(888) 312-8812 Login SignupRAYBESTOS 980397 Raybestos Specialty - Truck Brake Rotor
$93.87
MSRP Pricing shown.
Out of Stock
We cannot fulfill orders for this part at this time. Please check back later or request a stock notification to receive an email.
We may have similar parts for sale. Search Alternatives >
RAYBESTOS 980397 Part Description
Manufacturer
Product Description
Raybestos Specialty - Truck Brake Rotor
Application Summary
2010-2004 BMW X3 Front
Features & Benefits
- OE Fit, Form, and Function
- Our vehicle-specific design matches OE fit, form and function, providing ultimate strength and performance
- Cooling Vanes
- We dedicate time to match the cooling vanes on our Specialty rotors to OE designs, ensuring: Optimal cooling Reduced fade Less noise Increased pad life
- Coating
- All Specialty rotors are protected against the elements. All new Specialty rotors come fully coated with Grey Fusion 4.0® rated at 300 hrs. salt spray or a Black Fusion painted hat and edge for rust protection.
- All Specialty rotors are protected against the elements. All new Specialty rotors come fully coated with Grey Fusion 4.0(R) rated at 300 hrs. salt spray or a Black Fusion painted hat and edge for rust protection.
- SAE Standard for Tensile Strength
- Our rotors follow SAE standards for tensile strength, hardness, and iron grade, providing structural integrity and maximum service life
- Turned Finish
- A turned finish provides an excellent surface for the pads to engage with to ensure a smooth and effective stop right out of the box
RAYBESTOS 980397 Specifications
Product Attributes
| ABS Tone Ring Included | No |
| Center Hole Diameter | 2.953 IN |
| Center Hole Diameter | 75 MM |
| Conventional Or Drum-In-Hat Type Rotor | Conventional |
| Discard Thickness | 0.921 IN |
| Discard Thickness | 23.4 MM |
| Harmonize Code | 8708.30.5030 |
| Mounting Bolt Hole Circle Diameter | 4.724 IN |
| Mounting Bolt Hole Circle Diameter | 120 MM |
| Mounting Bolt Hole Diameter | 0.654 IN |
| Mounting Bolt Hole Diameter | 16.6 MM |
| Mounting Bolt Hole Quantity | 5 |
| Nominal Thickness | 0.984 IN |
| Nominal Thickness | 25 MM |
| Outside Diameter | 12.795 IN |
| Outside Diameter | 325 MM |
| Overall Height | 2.449 IN |
| Overall Height | 62.2 MM |
| Salability Restrictions | No |
| Solid Or Vented Type Rotor | Vented |
| Stud/Lug Hole Quantity | 5 |
| UNSPSC Code | 25171715 |
Additional Information
| Country of Origin (Primary) | CN |
| Canadian Harmonizing Tariff Code | 8708309990 |
| Harmonized Tariff Code (HTS) | 8708305030 |
| UPC | 00829352601211 |
RAYBESTOS 980397 Cross References
| Brand | Part Number |
|---|---|
| 829352601211, 120.34075 | |
| ADVANCE AUTO PARTS | N1000149742ZIC, YH200355, YH200355C, YH200355P |
| ATE BRAKE PRODUCTS | 425160, SP25160 |
| AUTOXTRA | AX900556 |
| AUTOZONE | 34351, 34351DG |
| BENDIX | BPR5860, PRT5860 |
| BMW | 34113400151 |
| BOSCH | 15011495 |
| BRAKEBEST | 15010130, 15011495, 980397, 980397FZN, 980397R, 980397RGS |
| BREMBO | 09.9581.11 |
| Brembo | 09.9581.1X |
| CENTRIC | 120.34075, 121.34075, 125.34075, 125.34075CRY, 126.34075CSL, 126.34075CSR, 126.34075SL, 126.34075SR, 127.34075L, 127.34075R, 128.34075CL, 128.34075CR, 128.34075L, 128.34075R, 320.34075, 320.34075H |
| Centric Parts | 120.34075, 121.34075, 125.34075, 125.34075CRY, 126.34075CSL, 126.34075CSR, 126.34075SL, 126.34075SR, 127.34075L, 127.34075R, 128.34075CL, 128.34075CR, 128.34075L, 128.34075R, 320.34075, 320.34075H |
| DURA CORP | BR34284, BR900556 |
| DuraGo | 900556, BR900556 |
| MAGMA PRODUCTS | PSR125109 |
| NAPA BRAKES | SDK6434, TSR4116, TSR9876 |
| NEOTEK | 106670GF |
| NEWTEK AUTOMOTIVE | 34284 |
| Newtek Automotive USA | 34284 |
| Omnicraft | QBRR579 |
| PAGID | 355122792 |
| PAGID Racing | 355122792 |
| POWERSTOP | EBR688EVC |
| PROMAX | 14-34284 |
| PRONTO | BR900556 |
| Qualis | 45410 |
| TRW | 4392, DF4392S, DF4116S |
| TopNotch | TN980397GEO |
| UAP | 34284 |
| VAICO | V2080005 |
| WAGNER | BD126526, BD126526E |
| WAGNER BRAKE | BD126526, BD126526E |
| WINHERE | 6620396 |
| WORLDPAC | 1407-75778, 1427-530139 |
RAYBESTOS 980397 Fits Vehicles
- BMW X3 (2004-2010)
