(888) 312-8812 Login SignupRAYBESTOS 980126 Raybestos Specialty - Street Performance Brake Rotor
$89.14
MSRP Pricing shown.
Out of Stock
We cannot fulfill orders for this part at this time. Please check back later or request a stock notification to receive an email.
We may have similar parts for sale. Search Alternatives >
RAYBESTOS 980126 Part Description
Manufacturer
Product Description
Raybestos Specialty - Street Performance Brake Rotor
Application Summary
2006-2001 BMW 330Ci Rear, 2005-2001 BMW 330i Rear, 2005-2001 BMW 330xi Rear, 2005-2001 BMW 320i Rear
Features & Benefits
- Application Specific Enhanced Iron
- Raybestos® Performance Rotors are made with enhanced iron which suppresses noise and keeps brakes running cool, quiet and vibration free.
- Raybestos(R) Performance Rotors are made with enhanced iron which suppresses noise and keeps brakes running cool, quiet and vibration free.
- Cooling Vanes
- The cooling vanes match OE configurations and provide optimal cooling and reduced fade.
- Application Specific Coating
- Depending on the application, Performance Rotors will have one of the following finishes: Black fusion coating on the rotor hat Grey Fusion 4.0® coating on the entire rotor
- Depending on the application, Performance Rotors will have one of the following finishes: Black fusion coating on the rotor hat Grey Fusion 4.0(R) coating on the entire rotor
- Depending on the application, Performance Rotors will have one of the following finishes:Black fusion coating on the rotor hatGrey Fusion 4.0® coating on the entire rotor
- Black fusion coating on the rotor hat and Grey Fusion 4.0® coating on the rotor inboard surface and cooling vanes
- Black fusion coating on the rotor hat and Grey Fusion 4.0(R) coating on the rotor inboard surface and cooling vanes
- Turned Finish
- Turned finish minimizes noise and improves responsiveness for smoother stops.
- S-Groove Slot
- Depending on the application, some Raybestos® Performance Rotors are designed with a patented S-Groove Slot.
- Depending on the application, some Raybestos(R) Performance Rotors are designed with a patented S-Groove Slot.
RAYBESTOS 980126 Specifications
Product Attributes
| ABS Tone Ring Included | No |
| Center Hole Diameter | 2.953 IN |
| Center Hole Diameter | 75 MM |
| Conventional Or Drum-In-Hat Type Rotor | Conventional |
| Discard Thickness | 0.803 IN |
| Discard Thickness | 20.4 MM |
| Harmonize Code | 8708.30.5030 |
| Mounting Bolt Hole Circle Diameter | 4.724 IN |
| Mounting Bolt Hole Circle Diameter | 120 MM |
| Mounting Bolt Hole Diameter | 0.57 IN |
| Mounting Bolt Hole Diameter | 14.5 MM |
| Mounting Bolt Hole Quantity | 5 |
| Nominal Thickness | 0.858 IN |
| Nominal Thickness | 21.8 MM |
| Outside Diameter | 12.598 IN |
| Outside Diameter | 320 MM |
| Overall Height | 2.382 IN |
| Overall Height | 60.5 MM |
| Salability Restrictions | No |
| Solid Or Vented Type Rotor | Vented |
| Stud/Lug Hole Quantity | 5 |
| UNSPSC Code | 25171715 |
Additional Information
| Country of Origin (Primary) | IT |
| Canadian Harmonizing Tariff Code | 8708309990 |
| Harmonized Tariff Code (HTS) | 8708305030 |
| UPC | 00829352175514 |
RAYBESTOS 980126 Cross References
| Brand | Part Number |
|---|---|
| 829352175514, 120.34057 | |
| ADVANCE AUTO PARTS | YH145416, YH145416C |
| ATE BRAKE PRODUCTS | 422209, SP22209 |
| AUTOSPECIALTY | EBR654 |
| AUTOXTRA | 80980126, AX34219 |
| AUTOZONE | 34219 |
| BENDIX | 145416 |
| BMW | 34201166073 |
| BRAKEBEST | 15010066, 980126, 980126R, 980126RGS |
| BREMBO | 25734 |
| Brembo | 09.9590.11 |
| CENTRIC | 120.34057, 121.34057, 125.34057, 125.34057CRY, 126.34057CSL, 126.34057CSR, 126.34057SL, 126.34057SR, 127.34057CL, 127.34057L, 128.34057, 128.34057CL, 128.34057L, 226.34057SLT, 228.34057, 320.34057, 320.34057F |
| Casting Numbers | 325986 |
| Centric Parts | 120.34057, 121.34057, 125.34057, 125.34057CRY, 126.34057CSL, 126.34057CSR, 126.34057SL, 126.34057SR, 127.34057CL, 127.34057L, 128.34057CL, 128.34057L, 226.34057SLT, 320.34057, 320.34057F, 128.34057, 228.34057 |
| DURA CORP | BR34219 |
| DuraGo | BR34219 |
| MAGMA PRODUCTS | PSR123053 |
| MIGHTY DISTRIBUTING SYSTEM | 34219 |
| NAPA BRAKES | SDK6335 |
| NEOTEK | 106675GF |
| NEWTEK AUTOMOTIVE | 34219 |
| Newtek Automotive USA | 34219 |
| PAGID | 355107692 |
| PAGID Racing | 355107692 |
| PILENGA | V814 |
| POWERSTOP | EBR654EVC |
| PROMAX | 14-34219 |
| PRONTO | BR34219 |
| QUALIS | 34219 |
| QUINTON HAZELL | BDC5227 |
| TRUSTAR | 412600 |
| TRW | 4212 |
| UAP | 34219 |
| Ultra Brake | BM-773 |
| VAICO | V2080049 |
| VIPAR - VEHICLE INDUSRTY PARTS & MANUFACTURING | X51622 |
| WABCO | PS126246 |
| WABCO - Archived | PS126246 |
| WAGNER | BD126586, BD126246E |
| WAGNER BRAKE | BD126246 |
| WINHERE | 662914 |
| WORLDPAC | 1407-78270 |
| Wagner Brake | BD126246E |
RAYBESTOS 980126 Fits Vehicles
- BMW 320i (2001-2005)
- BMW 330xi (2001-2005)
- BMW 330i (2001-2005)
- BMW 330Ci (2001-2006)
