(888) 312-8812 Login SignupRAYBESTOS 76722 Raybestos Specialty - Street Performance Brake Rotor
$65.84
MSRP Pricing shown.
Out of Stock
We cannot fulfill orders for this part at this time. Please check back later or request a stock notification to receive an email.
We may have similar parts for sale. Search Alternatives >
RAYBESTOS 76722 Part Description
Manufacturer
Product Description
Raybestos Specialty - Street Performance Brake Rotor
Application Summary
2004-1998 Dodge Intrepid Front, 2004-1998 Chrysler 300M Front, 2004-1998 Chrysler Concorde Front, 2001-1999 Chrysler LHS Front, 2004-1998 Chrysler Intrepid Front
Features & Benefits
- Application Specific Enhanced Iron
- Raybestos® Performance Rotors are made with enhanced iron which suppresses noise and keeps brakes running cool, quiet and vibration free.
- Raybestos(R) Performance Rotors are made with enhanced iron which suppresses noise and keeps brakes running cool, quiet and vibration free.
- Cooling Vanes
- The cooling vanes match OE configurations and provide optimal cooling and reduced fade.
- Application Specific Coating
- Depending on the application, Performance Rotors will have one of the following finishes: Black fusion coating on the rotor hat Grey Fusion 4.0® coating on the entire rotor
- Depending on the application, Performance Rotors will have one of the following finishes: Black fusion coating on the rotor hat Grey Fusion 4.0(R) coating on the entire rotor
- Depending on the application, Performance Rotors will have one of the following finishes:Black fusion coating on the rotor hatGrey Fusion 4.0® coating on the entire rotor
- Black fusion coating on the rotor hat and Grey Fusion 4.0® coating on the rotor inboard surface and cooling vanes
- Black fusion coating on the rotor hat and Grey Fusion 4.0(R) coating on the rotor inboard surface and cooling vanes
- Turned Finish
- Turned finish minimizes noise and improves responsiveness for smoother stops.
- S-Groove Slot
- Depending on the application, some Raybestos® Performance Rotors are designed with a patented S-Groove Slot.
- Depending on the application, some Raybestos(R) Performance Rotors are designed with a patented S-Groove Slot.
RAYBESTOS 76722 Specifications
Product Attributes
| ABS Tone Ring Included | No |
| Center Hole Diameter | 2.89 IN |
| Center Hole Diameter | 73.4 MM |
| Conventional Or Drum-In-Hat Type Rotor | Conventional |
| Directional or Non-Directional Brake Surface | Non-Directional |
| Discard Thickness | 0.96 IN |
| Discard Thickness | 24.4 MM |
| Harmonize Code | 8708.30.5030 |
| Material | Cast Iron |
| Mounting Bolt Hole Circle Diameter | 4.5 IN |
| Mounting Bolt Hole Circle Diameter | 114.3 MM |
| Mounting Bolt Hole Diameter | 0.546 IN |
| Mounting Bolt Hole Diameter | 13.85 MM |
| Mounting Bolt Hole Quantity | 5 |
| Nominal Thickness | 1.025 IN |
| Nominal Thickness | 26.05 MM |
| Outside Diameter | 11.7 IN |
| Outside Diameter | 297.2 MM |
| Overall Height | 2.12 IN |
| Overall Height | 53.85 MM |
| Salability Restrictions | No |
| Solid Or Vented Type Rotor | Vented |
| Stud/Lug Hole Quantity | 5 |
| UNSPSC Code | 25171715 |
Additional Information
| Country of Origin (Primary) | CN |
| Canadian Harmonizing Tariff Code | 8708309990 |
| Harmonized Tariff Code (HTS) | 8708305030 |
| UPC | 00747730233758 |
RAYBESTOS 76722 Cross References
| Brand | Part Number |
|---|---|
| 6360-503, 747730233758 | |
| ADVANCE AUTO PARTS | 145198, N1000449553APO, YH145198, YH145198C, YH145198P |
| AMERICAN REMANUFACTURED | 89-32045 |
| AUTOSPECIALTY | AR8345, AR8345E |
| AUTOXTRA | 8076722, AX5386, AX5388 |
| AUTOZONE | 5386, 5386DG, DL5386 |
| BENDIX | 145198 |
| BOSCH | 16010177, RBR5386 |
| BRAKEBEST | 16010177, 76722, 76722FZN, 76722R, 76722RGS, 81-125638, BD125638 |
| BREMBO | 09.8818.85, 27203 |
| Brembo | 09.8818.81 |
| Bridgestone | 7005021 |
| CALIFORNIA DRUM & ROTOR | 125638 |
| CENTRIC | 120.63045, 120.63045CRY, 121.63045, 125.63045, 126.63045CSL, 126.63045CSR, 126.63045SL, 126.63045SR, 127.63045CL, 127.63045CR, 127.63045L, 127.63045R, 128.63045L, 128.63045R, 227.63045L, 227.63045R, 320.63045, 321.63045 |
| CHRYSLER | 04779044, 04779101AA, 4779044, 4779101AA |
| CONTINENTAL-CONTITECH | CW26717 |
| Casting Numbers | 211144-C, 325185 |
| Centric Parts | 120.63045, 120.63045CRY, 121.63045, 125.63045, 126.63045CSL, 126.63045CSR, 126.63045SL, 126.63045SR, 127.63045CL, 127.63045CR, 127.63045L, 127.63045R, 128.63045L, 128.63045R, 227.63045L, 227.63045R, 320.63045, 321.63045 |
| DURA CORP | BR5386 |
| DuraGo | BR5386 |
| EUROROTOR | 53206 |
| GREN | 608202 |
| GUARDIAN | 52-125638 |
| MAGMA PRODUCTS | PSR143053 |
| MIGHTY DISTRIBUTING SYSTEM | 5386 |
| MONROE BRAKES | BD125638 |
| NEOTEK | 107041GF |
| NEWTEK AUTOMOTIVE | 5386 |
| Newtek Automotive USA | 5386 |
| PARTS MASTER | P125638 |
| POWERSTOP | AR8345EVC |
| PROMAX | 14-5386 |
| PRONTO | BR5386 |
| QUALIS | 5386 |
| QUALITEE INTERNATIONAL | 64-91-110 |
| QUALITY BRAND | 5386 |
| STANDARD ROTORS AND DRUMS | 5386 |
| THE UNIVERSAL GROUP | 103268 |
| TRUSTAR | 491110, R91110 |
| TopNotch | TN76722GEO |
| UAP | 5386 |
| Universal | 103268 |
| VIPAR - VEHICLE INDUSRTY PARTS & MANUFACTURING | X51262 |
| WABCO | PS125638 |
| WABCO - Archived | PS125638 |
| WAGNER | BD125638, BD125638E |
| WAGNER BRAKE | BD125638 |
| WINHERE | 442491, YH2491 |
| WORLDPAC | 1407-25674 |
| Wagner Brake | BD125638E |
RAYBESTOS 76722 Fits Vehicles
- Chrysler 300M (1998-2004)
- Chrysler Concorde (1998-2004)
- Chrysler Intrepid (1998-2004)
- Chrysler LHS (1999-2001)
- Dodge Intrepid (1998-2004)
