(888) 312-8812 Login SignupRAYBESTOS 980045 Raybestos Specialty - Street Performance Brake Rotor
$63.53
MSRP Pricing shown.
Out of Stock
We cannot fulfill orders for this part at this time. Please check back later or request a stock notification to receive an email.
We may have similar parts for sale. Search Alternatives >
RAYBESTOS 980045 Part Description
Manufacturer
Product Description
Raybestos Specialty - Street Performance Brake Rotor
Application Summary
2009-2001 Volvo S60 Rear, 2007-2003 Volvo XC70 Rear, 2007-2001 Volvo V70 Rear, 2006-1999 Volvo S80 Rear
Features & Benefits
- Application Specific Enhanced Iron
- Raybestos® Performance Rotors are made with enhanced iron which suppresses noise and keeps brakes running cool, quiet and vibration free.
- Raybestos(R) Performance Rotors are made with enhanced iron which suppresses noise and keeps brakes running cool, quiet and vibration free.
- Cooling Vanes
- The cooling vanes match OE configurations and provide optimal cooling and reduced fade.
- Application Specific Coating
- Depending on the application, Performance Rotors will have one of the following finishes: Black fusion coating on the rotor hat Grey Fusion 4.0® coating on the entire rotor
- Depending on the application, Performance Rotors will have one of the following finishes: Black fusion coating on the rotor hat Grey Fusion 4.0(R) coating on the entire rotor
- Black fusion coating on the rotor hat and Grey Fusion 4.0® coating on the rotor inboard surface and cooling vanes
- Black fusion coating on the rotor hat and Grey Fusion 4.0(R) coating on the rotor inboard surface and cooling vanes
- Turned Finish
- Turned finish minimizes noise and improves responsiveness for smoother stops.
- S-Groove Slot
- Depending on the application, some Raybestos® Performance Rotors are designed with a patented S-Groove Slot.
- Depending on the application, some Raybestos(R) Performance Rotors are designed with a patented S-Groove Slot.
RAYBESTOS 980045 Specifications
Product Attributes
| ABS Tone Ring Included | No |
| Center Hole Diameter | 2.68 IN |
| Center Hole Diameter | 68.05 MM |
| Conventional Or Drum-In-Hat Type Rotor | Conventional |
| Directional or Non-Directional Brake Surface | Non-Directional |
| Discard Thickness | 0.394 IN |
| Discard Thickness | 10 MM |
| Harmonize Code | 8708.30.5030 |
| Material | Cast Iron |
| Mounting Bolt Hole Circle Diameter | 4.25 IN |
| Mounting Bolt Hole Circle Diameter | 107.95 MM |
| Mounting Bolt Hole Diameter | 0.645 IN |
| Mounting Bolt Hole Diameter | 16.4 MM |
| Mounting Bolt Hole Quantity | 5 |
| Nominal Thickness | 0.472 IN |
| Nominal Thickness | 12 MM |
| Outside Diameter | 11.339 IN |
| Outside Diameter | 288 MM |
| Overall Height | 2.551 IN |
| Overall Height | 64.8 MM |
| Salability Restrictions | No |
| Solid Or Vented Type Rotor | Solid |
| Stud/Lug Hole Quantity | 5 |
| UNSPSC Code | 25171715 |
Additional Information
| Country of Origin (Primary) | IT |
| Canadian Harmonizing Tariff Code | 8708309990 |
| Harmonized Tariff Code (HTS) | 8708305030 |
| UPC | 00829352038390 |
RAYBESTOS 980045 Cross References
| Brand | Part Number |
|---|---|
| 829352038390, 120.39025 | |
| ADVANCE AUTO PARTS | 145409, N100086955ZIC, YH145409, YH145409C, YH145409P |
| ATE BRAKE PRODUCTS | SP12151, 412151 |
| AUTOXTRA | 126218, 80980045, AX34206 |
| AUTOZONE | 34206, 34206DG |
| BENDIX | 145409 |
| BRAKEBEST | 52011349, 980045, 980045FZN, 980045R, 980045RGS, BD126218 |
| BREMBO | 08.7765.11, 25521 |
| Brembo | 08.7765.1X, 08.7765.75 |
| CENTRIC | 120.39025, 121.39025, 125.39025, 125.39025CRY, 125.39036CRY, 126.39025CSL, 126.39025CSR, 126.39025SL, 126.39025SR, 127.39025L, 127.39025R, 128.39025CL, 128.39025CR, 128.39025L, 128.39025R, 320.39025, 320.39025H, 321.39025 |
| CONTINENTAL-CONTITECH | CW12151 |
| Casting Numbers | 211401-C, 325618 |
| Centric Parts | 120.39025, 121.39025, 125.39025, 125.39025CRY, 125.39036CRY, 126.39025CSL, 126.39025CSR, 126.39025SL, 126.39025SR, 127.39025L, 127.39025R, 128.39025CL, 128.39025CR, 128.39025L, 128.39025R, 320.39025, 320.39025H, 321.39025 |
| DURA CORP | BR34206 |
| DuraGo | BR34206 |
| MAGMA PRODUCTS | PSR603023 |
| MIGHTY DISTRIBUTING SYSTEM | 34206 |
| MONROE BRAKES | BD126218 |
| N/A | 120.39036, 121.39036, 125.39036, 126.39036CSL, 126.39036CSR, 126.39036SL, 126.39036SR, 127.39036CL, 127.39036CR, 127.39036L, 127.39036R, 128.39036CL, 128.39036CR, 128.39036L, 128.39036R |
| NAPA BRAKES | SDK6037 |
| NEOTEK | 106467GF |
| NEWTEK AUTOMOTIVE | 34206 |
| Newtek Automotive USA | 34206 |
| PILENGA | 5263 |
| POWERSTOP | EBR634EVC |
| PROMAX | 14-34206 |
| PRONTO | BR34206 |
| QUALIS | 34206 |
| QUINTON HAZELL | BDC4729 |
| TRW | 4066, DF4066, DF4066S |
| TopNotch | TN980045GEO |
| UAP | 34206 |
| VAICO | V9540007 |
| VIPAR - VEHICLE INDUSRTY PARTS & MANUFACTURING | X51614 |
| VOLVO | 9434167, 94341670, 94341674 |
| WABCO | PS126218 |
| WABCO - Archived | PS126218 |
| WAGNER | BD126218, BD126218E |
| WAGNER BRAKE | BD126218 |
| WINHERE | 661409 |
| WORLDPAC | 1407-78758, 1427-496785 |
| Wagner Brake | BD126218E |
RAYBESTOS 980045 Fits Vehicles
- Volvo XC70 (2003-2007)
- Volvo V70 (2001-2007)
- Volvo S80 (1999-2006)
- Volvo S60 (2001-2009)
