(888) 312-8812 Login SignupRAYBESTOS 96819 Raybestos Specialty - Truck Brake Rotor
$58.17
MSRP Pricing shown.
Out of Stock
We cannot fulfill orders for this part at this time. Please check back later or request a stock notification to receive an email.
We may have similar parts for sale. Search Alternatives >
RAYBESTOS 96819 Part Description
Manufacturer
Product Description
Raybestos Specialty - Truck Brake Rotor
Application Summary
2003-1999 Lexus RX300 Rear, 2003-2001 Toyota Highlander Rear
Features & Benefits
- OE Fit, Form, and Function
- Our vehicle-specific design matches OE fit, form and function, providing ultimate strength and performance
- Cooling Vanes
- We dedicate time to match the cooling vanes on our Specialty rotors to OE designs, ensuring: Optimal cooling Reduced fade Less noise Increased pad life
- Coating
- All Specialty rotors are protected against the elements. All new Specialty rotors come fully coated with Grey Fusion 4.0® rated at 300 hrs. salt spray or a Black Fusion painted hat and edge for rust protection.
- All Specialty rotors are protected against the elements. All new Specialty rotors come fully coated with Grey Fusion 4.0(R) rated at 300 hrs. salt spray or a Black Fusion painted hat and edge for rust protection.
- SAE Standard for Tensile Strength
- Our rotors follow SAE standards for tensile strength, hardness, and iron grade, providing structural integrity and maximum service life
- Turned Finish
- A turned finish provides an excellent surface for the pads to engage with to ensure a smooth and effective stop right out of the box
RAYBESTOS 96819 Specifications
Product Attributes
| ABS Tone Ring Included | No |
| Center Hole Diameter | 2.44 IN |
| Center Hole Diameter | 62 MM |
| Conventional Or Drum-In-Hat Type Rotor | Drum-In-Hat |
| Directional or Non-Directional Brake Surface | Non-Directional |
| Discard Thickness | 0.354 IN |
| Discard Thickness | 9 MM |
| Harmonize Code | 8708.30.5030 |
| Material | Cast Iron |
| Mounting Bolt Hole Circle Diameter | 4.5 IN |
| Mounting Bolt Hole Circle Diameter | 114.3 MM |
| Mounting Bolt Hole Diameter | 0.411 IN |
| Mounting Bolt Hole Diameter | 10.45 MM |
| Mounting Bolt Hole Quantity | 5 |
| Nominal Thickness | 0.395 IN |
| Nominal Thickness | 10.05 MM |
| Outside Diameter | 11.34 IN |
| Outside Diameter | 288.05 MM |
| Overall Height | 2.36 IN |
| Overall Height | 59.95 MM |
| Salability Restrictions | No |
| Solid Or Vented Type Rotor | Vented |
| Stud/Lug Hole Quantity | 5 |
| UNSPSC Code | 25171715 |
Additional Information
| Country of Origin (Primary) | CN |
| Canadian Harmonizing Tariff Code | 8708309990 |
| Harmonized Tariff Code (HTS) | 8708305030 |
| UPC | 00747730520773 |
RAYBESTOS 96819 Cross References
| Brand | Part Number |
|---|---|
| 73R-0474, 747730520773 | |
| ADVANCE AUTO PARTS | 140039, 145221, N1000238293APO, YH145221, YH145221C, YH145221P |
| AMERICAN REMANUFACTURED | 89-22108 |
| ATE BRAKE PRODUCTS | 410712 |
| AUTOSPECIALTY | JBR738, JBR738E |
| AUTOXTRA | 8096819, AX31261 |
| AUTOZONE | 31261DG, 8188 |
| AutoZone | 31261 |
| Autoxtra | AX31261P |
| BECK/ARNLEY | 083-2819 |
| BENDIX | 145221 |
| BRAKEBEST | 50011229, 96819, 96819FZN, 96819R, 96819RGS, BD125682 |
| BREMBO | 08.A150.10 |
| Brembo | 08.A150.11 |
| CENTRIC | 120.44089, 121.44089, 126.44089CSL, 126.44089CSR, 126.44089SL, 126.44089SR, 127.44089CL, 127.44089CR, 127.44089L, 127.44089R, 128.44089CL, 128.44089CR, 128.44089L, 128.44089R, 320.44089, 321.44089 |
| CONTINENTAL-CONTITECH | CW10712 |
| Casting Numbers | 210790-C, 325589 |
| Centric Parts | 120.44089, 121.44089, 126.44089CSL, 126.44089CSR, 126.44089SL, 126.44089SR, 127.44089CL, 127.44089CR, 127.44089L, 127.44089R, 128.44089CL, 128.44089CR, 128.44089L, 128.44089R, 320.44089, 321.44089 |
| DURA CORP | BR31261 |
| DuraGo | BR31261 |
| GREN | 24401 |
| MAGMA PRODUCTS | PSR565159 |
| MIGHTY DISTRIBUTING SYSTEM | 31261 |
| MONROE BRAKES | BD125682 |
| NEOTEK | 106386GF |
| NEWTEK AUTOMOTIVE | 31261 |
| Newtek Automotive USA | 31261 |
| Omnicraft | QBRR17 |
| POWERSTOP | JBR738EVC |
| PROMAX | 14-31261 |
| PRONTO | BR31261 |
| QUALIS | 31261 |
| QUALITEE INTERNATIONAL | 64-79-245 |
| QUALITY BRAND | 31261, Q049 |
| STANDARD ROTORS AND DRUMS | 31261 |
| THE UNIVERSAL GROUP | 108058 |
| TOYOTA | 4243133080, 4243148020 |
| TRUSTAR | 479245, R79245 |
| TopNotch | TN96819GEO |
| UAP | 31261 |
| Universal | 108058 |
| VIPAR - VEHICLE INDUSRTY PARTS & MANUFACTURING | X51277 |
| WABCO | PS125682 |
| WABCO - Archived | PS125682 |
| WAGNER | BD125682, BD125682E |
| WAGNER BRAKE | BD125682, BD125682E |
| WINHERE | 441412 |
| WORLDPAC | 1407-79939 |
RAYBESTOS 96819 Fits Vehicles
- Toyota Highlander (2001-2003)
- Lexus RX300 (1999-2003)
