RAYBESTOS 680686 Raybestos Specialty - Truck Brake Rotor

(0)

$94.99

Limited availability at this price!

1 Day Lead Time

Get it by Friday, Sep 4
No Hassle Return Policy Details
Free Ground shipping on orders over $499 details
This item will ship about 1 day after the date of purchase.

RAYBESTOS 680686 Part Description

Manufacturer

RAYBESTOS

Product Description

Raybestos Specialty - Truck Brake Rotor

Application Summary

2019-2011 Ford Explorer Rear, 2014-2011 Ford Edge Rear, 2019-2009 Ford Taurus Rear, 2019-2009 Ford Flex Rear, 2015-2011 Lincoln MKX Rear, 2012-2009 Lincoln MKS Rear, 2019-2010 Lincoln MKT Rear, 2009 Ford Taurus X Rear

Features & Benefits

  • OE Fit, Form, and Function
  • Our vehicle-specific design matches OE fit, form and function, providing ultimate strength and performance
  • Cooling Vanes
  • We dedicate time to match the cooling vanes on our Specialty rotors to OE designs, ensuring: Optimal cooling Reduced fade Less noise Increased pad life
  • Coating
  • All Specialty rotors are protected against the elements. All new Specialty rotors come fully coated with Grey Fusion 4.0® rated at 300 hrs. salt spray or a Black Fusion painted hat and edge for rust protection.
  • All Specialty rotors are protected against the elements. All new Specialty rotors come fully coated with Grey Fusion 4.0(R) rated at 300 hrs. salt spray or a Black Fusion painted hat and edge for rust protection.
  • SAE Standard for Tensile Strength
  • Our rotors follow SAE standards for tensile strength, hardness, and iron grade, providing structural integrity and maximum service life
  • Turned Finish
  • A turned finish provides an excellent surface for the pads to engage with to ensure a smooth and effective stop right out of the box

RAYBESTOS 680686 Specifications

Product Attributes

Conventional Or Drum-In-Hat Type Rotor Conventional
Directional or Non-Directional Brake Surface Non-Directional
Discard Thickness 0.4 IN
Discard Thickness 9.9 MM
Harmonize Code 8708.30.5030
Material Cast Iron
Mounting Bolt Hole Circle Diameter 4.5 IN
Mounting Bolt Hole Circle Diameter 114.3 MM
Mounting Bolt Hole Diameter 0.6 IN
Mounting Bolt Hole Diameter 14.2 MM
Nominal Thickness 0.4 IN
Nominal Thickness 10.9 MM
Salability Restrictions No
Stud/Lug Hole Quantity 5
UNSPSC Code 25171715
ABS Tone Ring Included No
Center Hole Diameter 2.7 IN
Center Hole Diameter 68.0 MM
Inside Diameter 8.9 IN
Inside Diameter 225.5 MM
Mounting Bolt Hole Quantity 5
Outside Diameter 8.7 IN
Outside Diameter 221.0 MM
Overall Height 1.5 IN
Overall Height 38.7 MM
Solid Or Vented Type Rotor Solid
Surface Type Smooth
Bearings Included No
Construction Full Cast
Grade Type Regular
Maximum Brake Diameter (Discard) 330.0 MM
Rust Resistant Coating Yes
Weight [cntrc] Kgs 6.6
Weight [cntrc] Lbs 14.5

Additional Information

Country of Origin (Primary) CN
Canadian Harmonizing Tariff Code 8708309990
Harmonized Tariff Code (HTS) 8708305030
UPC 00829352675526

RAYBESTOS 680686 Cross References

BrandPart Number
DYN-6235, 829352675526
ADVANCE AUTO PARTSG09289SD
AUTOPARTSOURCE592675
AUTOXTRAAX900928
AUTOZONE42262, 42262DG, 42266
AutoxtraAX900928P
BENDIXPRT5898
BOSCH20010394
BRAKEBEST20010394, 680686, 680686FZN, 680686PER, 680686R
BREMBO08.B584.10
BrakeBest680686RGS
CENTRIC120.61081
Centric Parts120.61081, 121.61081
DURA CORPBR54165, BR900928, BR900928-02
DuraGoBR900928, BR900928-01
Eurorotor54219
FORD8G1Z2C026B, BT4Z2C026A, BT4Z2C026B, AG1Z2C026A
Ford5U2Z1V125GD
MAGMA PRODUCTSPSR205236
NEWTEK AUTOMOTIVE54165
Newtek Automotive USA54165
PROMAX14-54165, 20-54165
PRONTOBR900928
Parts Master900928
TopNotchTN680686GEO
Ultra Brake54219
WINHERE661815
WORLDPAC1407-26921

RAYBESTOS 680686 Fits Vehicles

  • Lincoln MKX (2011-2015)
  • Ford Explorer (2011-2019)
  • Ford Edge (2011-2014)
  • Lincoln MKT (2010-2019)
  • Mercury Sable (2009)
  • Ford Taurus X (2009)
  • Ford Taurus (2009-2019)
  • Lincoln MKS (2009-2012)
  • Ford Flex (2009-2019)
