RAYBESTOS 76955 Part Description
Manufacturer
Product Description
Raybestos Specialty - Street Performance Brake Rotor
Application Summary
2010-2001 Chrysler PT Cruiser Front
Features & Benefits
- Application Specific Enhanced Iron
- Raybestos® Performance Rotors are made with enhanced iron which suppresses noise and keeps brakes running cool, quiet and vibration free.
- Raybestos(R) Performance Rotors are made with enhanced iron which suppresses noise and keeps brakes running cool, quiet and vibration free.
- Cooling Vanes
- The cooling vanes match OE configurations and provide optimal cooling and reduced fade.
- Application Specific Coating
- Depending on the application, Performance Rotors will have one of the following finishes: Black fusion coating on the rotor hat Grey Fusion 4.0® coating on the entire rotor
- Depending on the application, Performance Rotors will have one of the following finishes: Black fusion coating on the rotor hat Grey Fusion 4.0(R) coating on the entire rotor
- Black fusion coating on the rotor hat and Grey Fusion 4.0® coating on the rotor inboard surface and cooling vanes
- Black fusion coating on the rotor hat and Grey Fusion 4.0(R) coating on the rotor inboard surface and cooling vanes
- Turned Finish
- Turned finish minimizes noise and improves responsiveness for smoother stops.
- S-Groove Slot
- Depending on the application, some Raybestos® Performance Rotors are designed with a patented S-Groove Slot.
- Depending on the application, some Raybestos(R) Performance Rotors are designed with a patented S-Groove Slot.
RAYBESTOS 76955 Specifications
Product Attributes
| ABS Tone Ring Included | No |
| Center Hole Diameter | 2.4 IN |
| Center Hole Diameter | 60.95 MM |
| Conventional Or Drum-In-Hat Type Rotor | Conventional |
| Directional or Non-Directional Brake Surface | Non-Directional |
| Discard Thickness | 0.843 IN |
| Discard Thickness | 21.4 MM |
| Harmonize Code | 8708.30.5030 |
| Material | Cast Iron |
| Mounting Bolt Hole Circle Diameter | 3.93 IN |
| Mounting Bolt Hole Circle Diameter | 99.8 MM |
| Mounting Bolt Hole Diameter | 0.557 IN |
| Mounting Bolt Hole Diameter | 14.15 MM |
| Mounting Bolt Hole Quantity | 5 |
| Nominal Thickness | 0.905 IN |
| Nominal Thickness | 23 MM |
| Outside Diameter | 11.025 IN |
| Outside Diameter | 280.05 MM |
| Overall Height | 1.54 IN |
| Overall Height | 39.1 MM |
| Salability Restrictions | No |
| Solid Or Vented Type Rotor | Vented |
| Stud/Lug Hole Quantity | 5 |
| UNSPSC Code | 25171715 |
Additional Information
| Country of Origin (Primary) | CN |
| Canadian Harmonizing Tariff Code | 8708309990 |
| Harmonized Tariff Code (HTS) | 8708305030 |
| UPC | 00747730724997 |
RAYBESTOS 76955 Cross References
| Brand | Part Number |
|---|---|
| 74823011, 747730724997 | |
| ADVANCE AUTO PARTS | 145301, YH145301, YH145301C, YH145301P |
| AMERICAN REMANUFACTURED | 89-32051 |
| AUTOSPECIALTY | AR8351, AR8351E |
| AUTOXTRA | AX53000 |
| AUTOZONE | 53000, 53000DG, DL53000 |
| BENDIX | 145301 |
| BOSCH | 16010147 |
| BRAKEBEST | 16010147, 76955, 76955FZN, 76955R, 76955RGS, 81-125762, BD125762 |
| BREMBO | 09.8918.85, 09.9133.80, 27227 |
| Brembo | 09.9133.81 |
| CENTRIC | 120.63052, 121.63052, 125.63052, 126.63052CSL, 126.63052CSR, 126.63052SL, 126.63052SR, 127.63052CL, 127.63052CR, 127.63052L, 127.63052R, 128.63052CL, 128.63052CR, 128.63052L, 128.63052R, 227.63052L, 227.63052R, 320.63052, 320.63052F, 321.63052 |
| CHRYSLER | 04509994AA, 04509994AB, 4509994AA, 4509994AB, 4509994AD |
| CONTINENTAL-CONTITECH | CW23707 |
| Casting Numbers | 211303-C, 325528, 994AA, 994AD |
| Centric Parts | 120.63052, 121.63052, 125.63052, 126.63052CSL, 126.63052CSR, 126.63052SL, 126.63052SR, 127.63052CL, 127.63052CR, 127.63052L, 127.63052R, 128.63052CL, 128.63052CR, 128.63052L, 128.63052R, 227.63052L, 227.63052R, 320.63052, 320.63052F, 321.63052 |
| DURA CORP | BR53000, BR5300002 |
| DuraGo | BR53000, BR5300002 |
| GREN | 600002 |
| GUARDIAN | 52-125762 |
| MAGMA PRODUCTS | PSR143058 |
| MIGHTY DISTRIBUTING SYSTEM | 53000 |
| MONROE BRAKES | BD125762 |
| NAPA BRAKES | SDK6339, TSR288 |
| NEOTEK | 107052GF |
| NEWTEK AUTOMOTIVE | 53000 |
| Newtek Automotive USA | 53000 |
| Omnicraft | QBRR172 |
| POWERSTOP | AR8351EVC |
| PROMAX | 14-53000 |
| PRONTO | BR53000 |
| QUALIS | 53000 |
| QUALITEE INTERNATIONAL | 64-91-150 |
| QUALITY BRAND | 53000, Q4073 |
| QUINTON HAZELL | BDC5339 |
| STANDARD ROTORS AND DRUMS | 53000 |
| THE UNIVERSAL GROUP | 103114 |
| TRUSTAR | 491150, R91150 |
| TRW | DF2812S, DF4190 |
| TopNotch | TN76955GEO |
| UAP | 2053000, 53000 |
| Ultra Brake | 53230 |
| Universal | 103114 |
| VAICO | V3380002 |
| VIPAR - VEHICLE INDUSRTY PARTS & MANUFACTURING | X51363 |
| WABCO | PS125762 |
| WABCO - Archived | PS125762 |
| WAGNER | BD125762 |
| WAGNER BRAKE | BD125762 |
| WINHERE | 662668, YH2668 |
| WORLDPAC | 1407-25710 |
| Wagner Brake | BD125762E |
RAYBESTOS 76955 Fits Vehicles
- Chrysler PT Cruiser (2001-2010)
