RAYBESTOS 76161 Part Description
Manufacturer
Product Description
Raybestos Specialty - Truck Brake Rotor
Application Summary
1995-1991 Dodge Caravan Front, 1995-1991 Dodge Grand Caravan Front, 1995-1991 Plymouth Voyager Front, 1995-1991 Plymouth Grand Voyager Front, 1995-1991 Chrysler Town & Country Front
Features & Benefits
- OE Fit, Form, and Function
- Our vehicle-specific design matches OE fit, form and function, providing ultimate strength and performance
- Cooling Vanes
- We dedicate time to match the cooling vanes on our Specialty rotors to OE designs, ensuring: Optimal cooling Reduced fade Less noise Increased pad life
- Coating
- All Specialty rotors are protected against the elements. All new Specialty rotors come fully coated with Grey Fusion 4.0® rated at 300 hrs. salt spray or a Black Fusion painted hat and edge for rust protection.
- All Specialty rotors are protected against the elements. All new Specialty rotors come fully coated with Grey Fusion 4.0(R) rated at 300 hrs. salt spray or a Black Fusion painted hat and edge for rust protection.
- SAE Standard for Tensile Strength
- Our rotors follow SAE standards for tensile strength, hardness, and iron grade, providing structural integrity and maximum service life
- Turned Finish
- A turned finish provides an excellent surface for the pads to engage with to ensure a smooth and effective stop right out of the box
RAYBESTOS 76161 Specifications
Product Attributes
| ABS Tone Ring Included | No |
| Center Hole Diameter | 2.89 IN |
| Center Hole Diameter | 73.4 MM |
| Conventional Or Drum-In-Hat Type Rotor | Conventional |
| Directional or Non-Directional Brake Surface | Non-Directional |
| Discard Thickness | 0.882 IN |
| Discard Thickness | 22.4 MM |
| Harmonize Code | 8708.30.5030 |
| Material | Cast Iron |
| Mounting Bolt Hole Circle Diameter | 4.5 IN |
| Mounting Bolt Hole Circle Diameter | 114.3 MM |
| Mounting Bolt Hole Diameter | 0.552 IN |
| Mounting Bolt Hole Diameter | 14 MM |
| Mounting Bolt Hole Quantity | 5 |
| Nominal Thickness | 0.945 IN |
| Nominal Thickness | 24 MM |
| Outside Diameter | 11.1 IN |
| Outside Diameter | 281.95 MM |
| Overall Height | 1.505 IN |
| Overall Height | 38.25 MM |
| Salability Restrictions | No |
| Solid Or Vented Type Rotor | Vented |
| Stud/Lug Hole Quantity | 5 |
| UNSPSC Code | 25171715 |
Additional Information
| Country of Origin (Primary) | CN |
| Canadian Harmonizing Tariff Code | 8708309990 |
| Harmonized Tariff Code (HTS) | 8708305030 |
| UPC | 00030999297303 |
RAYBESTOS 76161 Cross References
| Brand | Part Number |
|---|---|
| 21-12358, 30999297303 | |
| ADVANCE AUTO PARTS | 141576, YH141576, YH141576C, YH141576P |
| AMERICAN REMANUFACTURED | 789-40021, 89-40021 |
| AUTOPART INTERNATIONAL | 25079 |
| AUTOSPECIALTY | AR8721, AR8721E |
| AUTOXTRA | 8076161, AX5346 |
| AUTOZONE | 5346, 5346B, 5346DG, 5346DL, DL5346 |
| BENDIX | 141576 |
| BOSCH | 16010154, RBR5346 |
| BRAKE PRO | 4616161 |
| BRAKEBEST | 16010154, 76161, 76161FZN, 76161R, 76161RGS, 81-125156, BD125156 |
| BREMBO | 09.5801.10, 27004 |
| Bridgestone | 7095141 |
| CALIFORNIA DRUM & ROTOR | 125156 |
| CENTRIC | 120.67021, 121.67021, 125.67021, 126.67021CSR, 126.67021SL, 126.67021SR, 127.67021L, 127.67021R, 320.67021, 320.67021F |
| CENTURY | 7053 |
| CHRYSLER | 04423368, 04509340, 4423368, 4509340 |
| CONTINENTAL-CONTITECH | CW24715 |
| Casting Numbers | 210509-C, 325164, 4653, 83461 |
| Centric Parts | 120.67021, 121.67021, 125.67021, 126.67021CSR, 126.67021SL, 126.67021SR, 127.67021L, 127.67021R, 320.67021, 320.67021F |
| DELPHI | RB344 |
| DURA CORP | BR5346, BR534602 |
| DuraGo | BR5346, BR5346-02 |
| EIS BRAKES | D17568 |
| EUROROTOR | 5371 |
| GREN | 601702 |
| GUARDIAN | 52-125156 |
| MAGMA PRODUCTS | PSR145124 |
| MIDAS | BR1786 |
| MIGHTY DISTRIBUTING SYSTEM | 5346 |
| MONROE BRAKES | BD125156 |
| NEOTEK | 107025GF |
| NEWTEK AUTOMOTIVE | 5346 |
| Newtek Automotive USA | 5346 |
| PROMAX | 14-5346 |
| PRONTO | BR5346 |
| QUALIS | 5346 |
| QUALITEE INTERNATIONAL | 64-91-780 |
| QUALITY BRAND | 5346 |
| ROADMATES | 526163 |
| ROCKHILL | 5346 |
| SEARS | 17785 |
| STANDARD ROTORS AND DRUMS | 5346 |
| THE UNIVERSAL GROUP | 103460 |
| TRUSTAR | 491780, R91780 |
| TRW | DF2678S |
| UAP | 5346 |
| Ultra Brake | 5371 |
| Universal | 103460 |
| VAICO | V3380001, V3380004 |
| VIPAR - VEHICLE INDUSRTY PARTS & MANUFACTURING | X50643 |
| WABCO | PS5346 |
| WABCO - Archived | PS5346 |
| WAGNER | BD125156 |
| WAGNER BRAKE | BD125156 |
| WINHERE | 442170, YH2170 |
RAYBESTOS 76161 Fits Vehicles
- Plymouth Voyager (1991-1996)
- Plymouth Grand Voyager (1991-1995)
- Dodge Grand Caravan (1991-1996)
- Dodge Caravan (1991-1996)
- Chrysler Town & Country (1991-1996)
