(888) 312-8812 Login SignupRAYBESTOS 9177R Raybestos R-Line Brake Rotor
MSRP: $66.32
$4999
Save $16.33
Limited availability at this price!
In Stock
Get it by Wednesday, Sep 2
RAYBESTOS 9177R Part Description
Manufacturer
Product Description
Raybestos R-Line Brake Rotor
Application Summary
2001-1997 Honda CR-V Front, 2001-2000,1998-1997 Acura Integra Front, 2001-1997 Honda Prelude Front, 1998-1995 Honda Odyssey Front, 1995-1991 Acura Legend Front, 1998-1996 Acura RL Front, 1998-1996 Acura TL Front
Features & Benefits
- OE Fit, Form, and Function
- Developed from OE samples and made with G3000-qualified material, ensuring OE fit, form and function for dependable braking.
- SAE Standard
- R-Line Rotors meet the SAE standard for tensile strength, providing structural integrity and a maximum service life.
- Low Initial Lateral Runout and Thickness Variation
- R-Line Rotors have a small parameter lateral runout and a thickness variation ensuring less pedal pulsation, less brake noise, and an extended pad life.
- Mill Balanced Edges
- R-Line Rotors are mill balanced and 100 percent validated. This helps minimize the thickness variation on the rotor and leads to minimized vibration and smoother stopping.
RAYBESTOS 9177R Specifications
Product Attributes
| ABS Tone Ring Included | No |
| Center Hole Diameter | 2.76 IN |
| Center Hole Diameter | 70.1 MM |
| Conventional Or Drum-In-Hat Type Rotor | Conventional |
| Directional or Non-Directional Brake Surface | Non-Directional |
| Discard Thickness | 0.827 IN |
| Discard Thickness | 21 MM |
| Harmonize Code | 8708.30.5030 |
| Material | Cast Iron |
| Mounting Bolt Hole Circle Diameter | 4.5 IN |
| Mounting Bolt Hole Circle Diameter | 114.3 MM |
| Mounting Bolt Hole Diameter | 0.5 IN |
| Mounting Bolt Hole Diameter | 12.7 MM |
| Mounting Bolt Hole Quantity | 5 |
| Nominal Thickness | 0.905 IN |
| Nominal Thickness | 23 MM |
| Outside Diameter | 11.08 IN |
| Outside Diameter | 281.45 MM |
| Overall Height | 1.85 IN |
| Overall Height | 47 MM |
| Salability Restrictions | No |
| Solid Or Vented Type Rotor | Vented |
| Stud/Lug Hole Quantity | 5 |
| UNSPSC Code | 25171715 |
Additional Information
| Country of Origin (Primary) | CN |
| Canadian Harmonizing Tariff Code | 8708309990 |
| Harmonized Tariff Code (HTS) | 8708305030 |
| UPC | 00829352367858 |
RAYBESTOS 9177R Cross References
| Brand | Part Number |
|---|---|
| 829352367858 | |
| ADVANCE AUTO PARTS | 141513, YH141513, YH141513C, YH141513P |
| ALTROM IMPORTS | A03296 |
| AMERICAN REMANUFACTURED | 789-08027, 89-08027 |
| AUTOPART INTERNATIONAL | 78295 |
| AUTOSPECIALTY | JBR528, JBR528E |
| AUTOXTRA | 125518, 809177, AX3296 |
| AUTOZONE | 3296, 3296B, 3296DG, DL3296 |
| BECK/ARNLEY | 080-2433, 083-2433, 083-2719, 083-2734 |
| BENDIX | 141513 |
| BOSCH | RBR3296 |
| BRAKE HEADQUARTERS | BR02037 |
| BRAKE PRO | 4613296 |
| BRAKEBEST | 26010735, 81-125518, 9177, 9177FZN, 9177R, 9177RGS, BD125518 |
| BREMBO | 09.6893.10, 25464 |
| Brembo | 09.6893.11 |
| CALIFORNIA DRUM & ROTOR | 125219, 125518 |
| CENTRIC | 120.40026, 120.40026CRY, 121.40026, 125.40026, 126.40026CSL, 126.40026CSR, 126.40026SL, 126.40026SR, 127.40026CL, 127.40026CR, 127.40026L, 127.40026R, 128.40026CL, 128.40026CR, 128.40026L, 128.40026R, 227.40026L, 227.40026R, 320.40026, 321.40026 |
| CENTURY | 9690 |
| CONTINENTAL-CONTITECH | CW23104 |
| Casting Numbers | 210514-C, 325106, 32961 |
| Centric Parts | 120.40026, 120.40026CRY, 121.40026, 125.40026, 126.40026CSL, 126.40026CSR, 126.40026SL, 126.40026SR, 127.40026CL, 127.40026CR, 127.40026L, 127.40026R, 128.40026CL, 128.40026CR, 128.40026L, 128.40026R, 227.40026L, 227.40026R, 320.40026, 321.40026 |
| DELPHI | RB366 |
| DURA CORP | BR3296 |
| DuraGo | BR3296 |
| EIS BRAKES | D17684 |
| EUROROTOR | HO558 |
| GM | 86203055 |
| GREN | 44002 |
| GUARDIAN | 52-125219, 52-125518 |
| General Motors | 86203055 |
| HONDA | 45251S2HN00, 45251SP0000, 45251SZ3000 |
| ISUZU | 5862030550 |
| ITM ENGINE COMPONENTS | 1601010 |
| MAGMA PRODUCTS | PMR265083 |
| MCI | 3706 |
| MIDAS | BR1741 |
| MIGHTY DISTRIBUTING SYSTEM | 3296 |
| MONROE BRAKES | BD125518 |
| NAPA BRAKES | SDK6237, TSR478, TSR693 |
| NEWTEK AUTOMOTIVE | 3296 |
| Newtek Automotive USA | 3296 |
| Omnicraft | QBRR116 |
| PARTS MASTER | P125518 |
| POWERSTOP | JBR528EVC |
| PROMAX | 14-3296 |
| QUALIS | 3296 |
| QUALITEE INTERNATIONAL | 64-71-090 |
| QUALITY BRAND | 3296, Q201 |
| QUINTON HAZELL | BDC4809 |
| ROADMATES | 526679 |
| STANDARD ROTORS AND DRUMS | 3296 |
| THE UNIVERSAL GROUP | 115960 |
| TRUSTAR | 471090, R71090 |
| TRW | 4028, DF4028S, DF4441S |
| TopNotch | TN9177GEO |
| UAP | 3296 |
| Ultra Brake | HO-558 |
| Universal | 115960 |
| VIPAR - VEHICLE INDUSRTY PARTS & MANUFACTURING | X50629 |
| WABCO | PS125518 |
| WABCO - Archived | PS125518 |
| WAGNER | BD125518, BD125518E |
| WAGNER BRAKE | BD125219, BD125518 |
| WINHERE | 442144, YH2144 |
| WORLDPAC | 1407-78295 |
| Wagner Brake | BD125518E |
RAYBESTOS 9177R Fits Vehicles
- Honda Prelude (1997-2001)
- Honda Odyssey (1995-1998)
- Honda CR-V (1997-2001)
- Acura TL (1996-1998)
- Acura RL (1996-1998)
- Acura Legend (1991-1995)
- Acura Integra (1997-2001)
- Isuzu Oasis (1996-1999)
