(888) 312-8812 Login SignupRAYBESTOS 56168R Raybestos R-Line Brake Rotor
$22.65
MSRP Pricing shown.
Out of Stock
We cannot fulfill orders for this part at this time. Please check back later or request a stock notification to receive an email.
We may have similar parts for sale. Search Alternatives >
RAYBESTOS 56168R Part Description
Manufacturer
Product Description
Raybestos R-Line Brake Rotor
Application Summary
1998-1991 Saturn SL2 Rear, 2002-1993 Saturn SC2 Rear, 1998-1991 Saturn SL1 Rear, 2002-1993 Saturn SC1 Rear, 1998-1993 Saturn SW2 Rear, 1998-1991 Saturn SL Rear, 1998-1993 Saturn SW1 Rear, 1992-1991 Saturn SC Rear
Features & Benefits
- OE Fit, Form, and Function
- Developed from OE samples and made with G3000-qualified material, ensuring OE fit, form and function for dependable braking.
- SAE Standard
- R-Line Rotors meet the SAE standard for tensile strength, providing structural integrity and a maximum service life.
- Low Initial Lateral Runout and Thickness Variation
- R-Line Rotors have a small parameter lateral runout and a thickness variation ensuring less pedal pulsation, less brake noise, and an extended pad life.
- Mill Balanced Edges
- R-Line Rotors are mill balanced and 100 percent validated. This helps minimize the thickness variation on the rotor and leads to minimized vibration and smoother stopping.
RAYBESTOS 56168R Specifications
Product Attributes
| ABS Tone Ring Included | No |
| Center Hole Diameter | 2.266 IN |
| Center Hole Diameter | 57.55 MM |
| Conventional Or Drum-In-Hat Type Rotor | Conventional |
| Discard Thickness | 0.354 IN |
| Discard Thickness | 9 MM |
| Harmonize Code | 8708.30.5030 |
| Mounting Bolt Hole Circle Diameter | 3.937 IN |
| Mounting Bolt Hole Circle Diameter | 100 MM |
| Mounting Bolt Hole Diameter | 3.937 IN |
| Mounting Bolt Hole Diameter | 100 MM |
| Mounting Bolt Hole Quantity | 4 |
| Nominal Thickness | 0.435 IN |
| Nominal Thickness | 11.05 MM |
| Outside Diameter | 9.64 IN |
| Outside Diameter | 244.85 MM |
| Overall Height | 1.63 IN |
| Overall Height | 41.4 MM |
| Salability Restrictions | No |
| Solid Or Vented Type Rotor | Solid |
| Stud/Lug Hole Quantity | 4 |
| UNSPSC Code | 25171715 |
Additional Information
| Country of Origin (Primary) | CN |
| Canadian Harmonizing Tariff Code | 8708309990 |
| Harmonized Tariff Code (HTS) | 8708305030 |
| UPC | 00829352364031 |
RAYBESTOS 56168R Cross References
| Brand | Part Number |
|---|---|
| 85827070, 829352364031 | |
| ADVANCE AUTO PARTS | 141605, YH141605 |
| AMERICAN REMANUFACTURED | 789-36037, 89-36037 |
| AUTOPART INTERNATIONAL | 25072 |
| AUTOSPECIALTY | AR8237, AR8237E |
| AUTOZONE | 5582, 5582B, DL5582 |
| BENDIX | 141605 |
| BOSCH | 25010583, RBR5582 |
| BRAKE HEADQUARTERS | BR55752 |
| BRAKE PRO | 4615582 |
| BRAKEBEST | 25010583, 56168, 56168R, 56168RGS, 81-125138 |
| BREMBO | 08.8474.85, 27191 |
| CALIFORNIA DRUM & ROTOR | 125138 |
| CENTRIC | 120.62037, 121.62037, 125.62037, 126.62037CSL, 126.62037CSR, 126.62037SL, 126.62037SR, 127.62037L, 127.62037R, 128.62037CL, 128.62037CR, 128.62037L, 128.62037R, 320.62037, 320.62037F |
| CENTURY | 5084 |
| CONTINENTAL-CONTITECH | CW11706 |
| Casting Numbers | 210857-C, 325315, 55821 |
| Centric Parts | 120.62037, 121.62037, 125.62037, 126.62037CSL, 126.62037CSR, 126.62037SL, 126.62037SR, 127.62037L, 127.62037R, 128.62037CL, 128.62037CR, 128.62037L, 128.62037R, 320.62037, 320.62037F |
| DELPHI | RB53 |
| DURA CORP | BR5582 |
| DuraGo | BR5582 |
| EIS BRAKES | D17514 |
| EUROROTOR | 5582 |
| GREN | 686501 |
| GUARDIAN | 52-125138 |
| MAGMA PRODUCTS | PMR223050 |
| MCI | 6068 |
| MIDAS | BR1788 |
| MIGHTY DISTRIBUTING SYSTEM | 5582 |
| MONROE BRAKES | BD125138 |
| NEWTEK AUTOMOTIVE | 5582 |
| Newtek Automotive USA | 5582 |
| PARTS MASTER | P125138 |
| PROMAX | 14-5582 |
| QUALIS | 5582 |
| QUALITEE INTERNATIONAL | 64-93-760 |
| QUALITY BRAND | 5582 |
| ROADMATES | 526162 |
| ROCKHILL | 5582 |
| SATURN | 21011106, 21012665 |
| STANDARD ROTORS AND DRUMS | 5582 |
| THE UNIVERSAL GROUP | 101820 |
| TRUSTAR | 493760, R93760 |
| UAP | 5582 |
| Universal | 101820 |
| VIPAR - VEHICLE INDUSRTY PARTS & MANUFACTURING | X50583 |
| WAGNER | BD125138 |
| WAGNER BRAKE | BD125138, SB56168 |
| WINHERE | 441154, YH1154 |
RAYBESTOS 56168R Fits Vehicles
- Saturn SW2 (1993-2001)
- Saturn SW1 (1993-1999)
- Saturn SL2 (1991-2002)
- Saturn SL1 (1991-2002)
- Saturn SL (1991-2002)
- Saturn SC2 (1993-2002)
- Saturn SC (1991-1992)
- Saturn SC1 (1993-2002)
