HELLA 009168401 Part Description
Manufacturer
Product Description
HELLA Engine Camshaft Position Sensor 009168401
Features & Benefits
- Improves fuel efficiency and engine response by providing high air-mass measuring precision with hot-film sensor technology.
- Ensures accurate air-to-fuel ratio adjustment, supporting stable combustion efficiency and reduced engine emissions in varying conditions.
- Delivers long service life with robust sensor construction, designed for consistent performance in diverse environmental conditions.
- Enhances engine management with a broad dynamic measurement range that supports precise exhaust gas recirculation and accurate flow measurement.
- Offers universal compatibility, ensuring seamless integration with most modern vehicles for reliable sensor installation and operation.
Highest measuring precision in a wide ambient temperature range
HELLA 009168401 Specifications
Product Attributes
| Supplementary Article/Info 2 | with seal ring |
| Sensor Type | Hall Sensor |
| Assy./disassy. By Qualified Personnel Required! | . |
| Number of Pins | 3 |
| Assy/Disassy by Qualified Personnel Required! | . |
| California Proposition 65 Required | No |
| Supplementary Article/Supplementary Info 2 | with Seal Ring |
| Sensor Body Diameter [mm] | 15.10 |
| Sensor Casing Length | 24.00 MM |
| Sensor Casing Material | Plastic |
| Voltage | 12.00 2H |
| Color | Black |
| Bolt Hole Quantity | 1 |
| Terminal Type | Blade |
| Grade Type | Standard Replacement |
| Connector Quantity | 1 |
| Connector Shape | Rectangular |
| Gasket Or Seal Included | Yes |
| Terminal Quantity | 3 |
| Connector Gender | Male |
| Terminal Gender | Female |
| Wiring Harness Included | No |
| Mounting Hole Diameter | 6.70 MM |
| Gasket Or Seal Material | Rubber |
| Mounting Bracket Included | No |
| Seal Outside Diameter | 16.00 mm |
| Sensor Body Diameter [in] | 0.59 |
| Sensor Casing Length | 0.94 IN |
| 10797 | 0.59 IN |
| 10797 | 15.10 MM |
| Mounting Hole Diameter | 0.26 IN |
| Seal Outside Diameter | 0.62 IN |
Additional Information
| Harmonized Tariff Code (HTS) | 9031808085 |
| Warranty Time UOM | MO |
| Warranty Time | 12 |
| Country of Origin (Primary) | CN |
| UPC | 04082300852325 |
HELLA 009168401 Cross References
| Brand | Part Number |
|---|---|
| Audi | 04C 907 601, 04C907601K |
| N/A | 04C C90 760 K, CS-E202, 131894, 2501894, 255007, 81469, 0 986 280 610, 903266, 17211, 551477A, 9.0793, PAE907601, 185368, SS11473, V10-72-1319, V10-72-0187, 871064, 87940, 70630040, 64847220010, 79523, 147231, 303460, 2352122, 2352067, 04C907601A, 95890760100, CSA1788, PC984, CSS2249, CSS1975, 04C907601K, 04C907601 |
| Porsche | 95890760100 |
| STANDARD IGNITION | PC984 |
| Seat | 04C 907 601 |
| Skoda | 04C 907 601 |
| Volkswagen | 04C 907 601, 04C 907 601 A, 04C907601K |
HELLA 009168401 Fits Vehicles
- Volkswagen Atlas (2022-2023)
- Volkswagen Atlas Cross Sport (2022-2023)
- Audi A7 Sportback (2021)
- Audi Q5 PHEV (2020-2025)
- Audi TTS Quattro (2016-2023)
- Audi Q3 (2019-2025)
- Audi Q5 (2019-2020)
- Volkswagen Tiguan (2019-2025)
- Volkswagen Arteon (2019-2021)
- Audi A7 Quattro (2018)
- Audi A5 Sportback (2018-2020)
- Audi A5 Quattro (2018-2020)
- Audi A4 allroad (2017-2020)
- Volkswagen Golf Alltrack (2017, 2019)
- Volkswagen Golf R (2015-2019)
- Audi A4 Quattro (2017-2020)
- Audi A4 (2017-2020)
- Porsche Macan (2017-2021)
- Audi R8 (2017-2018, 2020-2023)
- Audi Q7 (2017-2022)
- Audi A3 Sportback e-tron (2016-2018)
- Audi TT Quattro (2016-2023)
- Volkswagen Golf SportWagen (2015-2017, 2019)
- Audi A6 Quattro (2016-2020)
- Audi A6 (2016-2018)
- Audi S3 (2015-2020)
- Volkswagen Golf (2015-2017, 2019-2021)
- Volkswagen GTI (2015-2017, 2019-2021)
- Audi A3 Quattro (2015-2020)
- Audi A3 (2015-2020)
- Volkswagen Passat (2014-2017, 2019-2021)
- Audi RS7 (2014-2018)
- Volkswagen Jetta (2013-2026)
- Volkswagen Beetle (2013-2019)
- Audi S6 (2013-2018)
- Audi S7 (2013-2018)
- Audi S8 (2013-2018)
- Audi A8 Quattro (2013-2018)
