HELLA 009168361 Part Description
Manufacturer
Product Description
HELLA Engine Camshaft Position Sensor 009168361
Features & Benefits
- Improves fuel efficiency and engine response by providing high air-mass measuring precision with hot-film sensor technology.
- Ensures accurate air-to-fuel ratio adjustment, supporting stable combustion efficiency and reduced engine emissions in varying conditions.
- Delivers long service life with robust sensor construction, designed for consistent performance in diverse environmental conditions.
- Enhances engine management with a broad dynamic measurement range that supports precise exhaust gas recirculation and accurate flow measurement.
- Offers universal compatibility, ensuring seamless integration with most modern vehicles for reliable sensor installation and operation.
Highest measuring precision in a wide ambient temperature range
HELLA 009168361 Specifications
Product Attributes
| Sensor Type | Hall Sensor |
| Supplementary Article/Info 2 | with seal ring |
| Assy./disassy. By Qualified Personnel Required! | . |
| Number of Pins | 3 |
| Assy/Disassy by Qualified Personnel Required! | . |
| California Proposition 65 Required | No |
| Supplementary Article/Supplementary Info 2 | with Seal Ring |
| Sensor Casing Length | 24.00 MM |
| Sensor Casing Material | Plastic |
| 10797 | 20.20 MM |
| Voltage | 12.00 2H |
| Color | Black |
| Bolt Hole Quantity | 1 |
| Terminal Type | Blade |
| Grade Type | Standard Replacement |
| Connector Quantity | 1 |
| Connector Shape | Rectangular |
| Gasket Or Seal Included | Yes |
| Terminal Quantity | 3 |
| Connector Gender | Male |
| Terminal Gender | Female |
| Wiring Harness Included | No |
| Mounting Hole Diameter | 6.80 MM |
| Gasket Or Seal Material | Rubber |
| Mounting Bracket Included | No |
| Seal Outside Diameter | 21.20 mm |
Additional Information
| Harmonized Tariff Code (HTS) | 9031808085 |
| Warranty Time UOM | MO |
| Warranty Time | 12 |
| Country of Origin (Primary) | CN |
| UPC | 04082300852288 |
HELLA 009168361 Cross References
| Brand | Part Number |
|---|---|
| Alfa Romeo | 93186840 |
| Chrysler | 05066856AA, 05066856AB, 5140332AA |
| Citroen | 1920-JH |
| Dodge | 05066856AA, 05066856AB, 05140332AA |
| Fiat | 46798367, 504048261, K05066856AB, K05140332AA |
| Ford | 1319158, 1826557, 4M5G12K073AA, 4M5G12K073AB |
| Hyundai | 39300-27400 |
| Jeep | 05066856AA, 05066856AB, 05140332AA |
| Kia | 39300-27400 |
| Lancia | 46798367, 504048261, K05066856AB, K05140332AA |
| Land Rover | LR000634, LR052493, LR058405 |
| N/A | 0506 6856AA, 0506 6856AB, 5140 332AA, 3612010-E06, 253804, 903111, 0 281 002 667, 232103067, 550292A, 550292, 2P0 133 491, 9.0361, 45 96 2070F, 40772, 86587260-0, Y0100-3823160, 129A0014710, V25-72-0087, 70630301, 64847192010, CS-E094, 5802260743, 8089 126 0, 81066, 281002667, CA100024160, 68095463AA, 5066856AA, 3611040RAA, 5066856AB, 93 347 211, 80891268, 32K9000100, 0305CC0011N, 87413E, 87413, 940700670074, 19078, 79350 |
| Opel | 6235685, 6235715, 93186840 |
| Peugeot | 1920-JH |
| Vauxhall | 93183528, 93186840, 93310500 |
| Volvo | 8658726, 8658726-0 |
HELLA 009168361 Fits Vehicles
- Ram ProMaster 3500 (2014-2018)
- Ram ProMaster 2500 (2014-2018)
- Ram ProMaster 1500 (2014-2017)
- Jeep Gladiator (2021-2023)
- Jeep Wrangler (2020-2023)
- Ram 1500 Classic (2019)
- Ram 1500 (2014-2018, 2020-2023)
- Jeep Grand Cherokee (2014-2019)
- Jeep Liberty (2005-2006)
