Centric 406.40025 - Centric Premium Hub and Bearing Assembly; With ABS
We cannot fulfill orders for this part at this time. Please check back later or request a stock notification to receive an email.
Sometimes we may have similar parts for sale, click the button below to see if anything matches.
CENTRIC part description
Product Description
Centric Premium Hub and Bearing Assembly; With ABS
Features & Benefits
- 100% O.E. Quality Components. Premium seals protect internal components. Exacting Fit and Function. Complete cataloging; featuring the latest applications and covering from 1940 to 2017
Product Attributes
| Bolt Circle Diameter [cntrc] In | 4.500 |
| Bolt Circle Diameter [cntrc] Mm | 114.300 |
| Inner Diameter [cntrc] In | 1.330 |
| Thread Pitch To Wheel Mounting [cntrc] Mm | 1.500 |
| Notes [cntrc] | Retaining Holes 2x M6-1.0; 5 Flange Holes 0.915" // ABS ring 50t |
| Inner Diameter [cntrc] Mm | 33.800 |
| Product Grade [cntrc] | Premium |
| Wheel Stud Size | 12.000 MM |
| Wheel Pilot Diameter | 64.010 MM |
| Wheel Pilot Diameter | 2.520 IN |
| Brake Pilot Diameter | 64.010 MM |
| Brake Pilot Diameter | 2.520 IN |
| Wheel Stud Quantity | 5 |
| Wheel Studs Included | Yes |
| Flange Diameter | 5.750 IN |
| Flange Diameter | 146.050 MM |
Additional Information
| Harmonized Tariff Code (HTS) | 8482105016 |
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | JP |
| UPC | 805890566861 |
Part Interchanges
Fits Vehicles
- Acura RL (2002-2004)
